Q40AW3FF400 Banner Proximity Sensors
Part#:Q40AW3FF400
Alt. Part#:32368
Manufacturer:Banner
Category:Proximity Sensors
Product Lifecycle:Active
Product description
EZ-BEAM Q40 Series: Fixed Field; Range: 400 mm; Input: 20-250 V ac; Output: SPST Solid-state Light Operate; 2 m (6.5 ft) Cable
Product Details
- Weight 248.568416 g
- Country Of Origin US
- Design background suppression system
- Supply voltage (AC) 20Vac-250Vac (200Vac / 220Vac / 240Vac nom.)
- Digital outputs 1 x digital output (Solid-state AC output; SPST contact type)
- Ambient air temperature for operation -40...+70 °C
- Primary brand Banner Engineering
- Sub-range name Q40 AC series
- Sensing distance 400mm
- Thread size M30
- Degree of protection IP67 NEMA 6P
- Compliant with standard(s) cULus CCC cCSAus CE
- Main function Sensor (Photo-electric)
- Functions Fixed-field photo-electric sensor green LED (power ON) amber LED (output state)
- Wavelength 880 nm
- Response time 16ms / 0.016 s
- Order code / Manufacturer SKU 32368
- Shape Rectangular
- Operating mode Light-ON
- Product series / family name EZ-BEAM series
- Light Color Infrared (IR)
- Connection type Pre-wired with 6.5ft / 2m cable terminated with bare end flying leads
- Material thermoplastic housing
- Max Sensing Distance (mm) 400
- Power Supply/Supply Voltage 20-250 V ac
- Special Feature: Water Detection No
- Feature: Audible No
- Sensing Mode (General) Proximity
- Min Op. Temp. (°C) -40
- IP Rating IP67
- Feature: Chemical Resistant No
- Housing Style Rectangular
- Quick Disconnect Type No QD
- Number of Pins 3
- IO Link No
- Primary Housing Material Thermoplastic
- Connection Cable
- Max Op. Relative Humidity [%] 90% @ 50°C
- Feature: Encapsulated Yes
- Sensing Mode (Detailed) Background Suppression (Fixed)
- Max Op. Temp. (°C) 70
- Lens Material Polycarbonate
- Feature: Hazardous Area No
- Power AC
- Operation Light Operate
- NEMA Rating NEMA 6P
- Feature: Timing (Hold/Delay) No
- Opposed Mode Emitter/Receiver N/A
- Input/Output Solid-State AC Switch
- Special Feature: Intrinsically Safe No
- Barrel Diameter (mm) 30
- Cable Length (m) 2
- Special Feature: Remote Teach No
- Delay at Power-up (ms) 100
- Feature: Ecolab Certified Yes
- Indicator LEDs
- Sensing Beam Infrared LED
- Outputs Solid-State AC Switch
- Repeatability (µs) 4000
- Adjustments N/A
- Output response time (ms) 16
- DeviceNet No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of Q40AW3FF400 on Powermatic Associates is $186.00. Order now.
About the product
Banner Engineering Q40AW3FF400 is a fixed-field photo-electric sensor designed for precise sensing tasks. It features a M30 threaded mount for secure installation and operates within an ambient air temperature range of -40 to +70°C. This sensor is equipped with a background suppression system to enhance its detection capabilities. It comes pre-wired with a 6.5ft / 2m cable that terminates with bare end flying leads for easy connection. The Q40AW3FF400 operates on a supply voltage of 20Vac-250Vac, with nominal values at 200Vac, 220Vac, and 240Vac, and is part of the Q40 AC series. It boasts a degree of protection rated at IP67 NEMA 6P, ensuring durability in harsh environments. The sensor's rectangular shape is constructed from a thermoplastic housing, offering a robust design. It has a sensing distance of 400mm and utilizes infrared light with a wavelength of 880 nm in a Light-ON operating mode. Additionally, it features 1 x digital output (Solid-state AC output; SPST contact type) with a response time of 16ms / 0.016 s.
