Powermatic Associates Logo

Q40AW3FF200 Banner Proximity Sensors

Q40AW3FF200 on Powermatic Associates
Banner

Part#:Q40AW3FF200

Alt. Part#:32365

Manufacturer:Banner

Category:Proximity Sensors

Product Lifecycle:Active

Product description

EZ-BEAM Q40 Series: Fixed Field; Range: 200 mm; Input: 20-250 V ac; Output: SPST Solid-state Light Operate; 2 m (6.5 ft) Cable

Product Details

  • Weight
    253.557928 g
  • Country Of Origin
    US
  • Primary Housing Material
    Thermoplastic
  • Min Op. Temp. (°C)
    -40
  • Repeatability (µs)
    4000
  • Feature: Ecolab Certified
    Yes
  • Max Sensing Distance (mm)
    200
  • Output response time (ms)
    16
  • Adjustments
    N/A
  • IO Link
    No
  • Connection
    Cable
  • Cable Length (m)
    2
  • Special Feature: Remote Teach
    No
  • Lens Material
    Polycarbonate
  • Feature: Encapsulated
    Yes
  • Sensing Mode (Detailed)
    Background Suppression (Fixed)
  • Quick Disconnect Type
    No QD
  • Special Feature: Water Detection
    No
  • Barrel Diameter (mm)
    30
  • Feature: Hazardous Area
    No
  • Sensing Beam
    Infrared LED
  • Operation
    Light Operate
  • IP Rating
    IP67
  • Opposed Mode Emitter/Receiver
    N/A
  • Input/Output
    Solid-State AC Switch
  • Max Op. Temp. (°C)
    70
  • Max Op. Relative Humidity [%]
    90% @ 50°C
  • DeviceNet
    No
  • Power Supply/Supply Voltage
    20-250 V ac
  • Sensing Mode (General)
    Proximity
  • Number of Pins
    3
  • Indicator
    LEDs
  • Feature: Audible
    No
  • Power
    AC
  • Outputs
    Solid-State AC Switch
  • Feature: Timing (Hold/Delay)
    No
  • Delay at Power-up (ms)
    100
  • Housing Style
    Rectangular
  • Special Feature: Intrinsically Safe
    No
  • NEMA Rating
    NEMA 6P
  • Feature: Chemical Resistant
    No

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of Q40AW3FF200 on Powermatic Associates is $186.00. Order now.

About the product

Banner Engineering Q40AW3FF200 is a fixed-field photo-electric sensor designed for precise sensing tasks. It features an M30 threaded mount for secure installation and operates within an ambient air temperature range of -40 to +70°C. This sensor is equipped with a background suppression system to enhance detection accuracy and is pre-wired with a 6.5ft / 2m cable that terminates with bare end flying leads for easy connection. It supports a supply voltage range of 20Vac-250Vac, with nominal values at 200Vac, 220Vac, and 240Vac, aligning with the Q40 AC series specifications. The Q40AW3FF200 offers an IP67 NEMA 6P degree of protection, ensuring durability in harsh environments. Its rectangular, thermoplastic housing is designed for longevity, and it has a sensing distance of 200mm. The sensor utilizes infrared light with a wavelength of 880 nm in a Light-ON operating mode. It features a single digital output (Solid-state AC output; SPST contact type) and boasts a quick response time of 16ms / 0.016 s.
