MIAD9LVQ
Banner
Product Lifecycle: Active
Banner Engineering MIAD9LVQ is a photo-electric sensor designed for versatile applications, featuring a retro-reflective mode with potentiometer adjustment. It comes in a rectangular shape with a thermoplastic housing and an acrylic lens. This sensor is mounted using an M18 threaded mount and is pre-equipped with a 4-pin Euro-style M12 connector for easy connection. It operates within an ambient air temperature range of -40 to +70°C and offers a sensing distance of up to 5 meters. The MIAD9LVQ operates on a supply voltage of 5Vdc to 15Vdc, with a nominal voltage of 12Vdc, and provides a single digital output (NAMUR) with a quick response time of 5ms. It emits visible red light and supports both Light-ON and Dark-ON operating modes. This sensor is part of the MIAD9 NAMUR series and is protected to IP67, NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, and 13 standards, ensuring durability in various environmental conditions.
![MIAD9LVQ](/_next/image?url=https%3A%2F%2Fappstoragepublicprod.s3.us-west-1.amazonaws.com%2FPartImage%2Fbb434eca-5853-4c01-8422-4f3e48344689.jpeg&w=3840&q=75)
Banner Engineering MIAD9LVQ is a photo-electric sensor designed for versatile applications, featuring a retro-reflective mode with potentiometer adjustment. It comes in a rectangular shape with a thermoplastic housing and an acrylic lens. This sensor is mounted using an M18 threaded mount and is pre-equipped with a 4-pin Euro-style M12 connector for easy connection. It operates within an ambient air temperature range of -40 to +70°C and offers a sensing distance of up to 5 meters. The MIAD9LVQ operates on a supply voltage of 5Vdc to 15Vdc, with a nominal voltage of 12Vdc, and provides a single digital output (NAMUR) with a quick response time of 5ms. It emits visible red light and supports both Light-ON and Dark-ON operating modes. This sensor is part of the MIAD9 NAMUR series and is protected to IP67, NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, and 13 standards, ensuring durability in various environmental conditions.
Product details
- IO LinkNo
- DeviceNetNo
- Feature: Chemical ResistantNo
- Feature: AudibleNo
- Feature: Hazardous AreaYes
- Feature: EncapsulatedYes
- Feature: Timing (Hold/Delay)No
- Opposed Mode Emitter/ReceiverN/A
- Max Op. Relative Humidity [%]90% @ 50°C
- NEMA RatingNEMA 1, 2, 3, 3S, 4, 4X, 6, 12, 13
- IP RatingIP67
- IndicatorLEDs
- Barrel Diameter (mm)18
- AdjustmentsPotentiometer
- Lens MaterialAcrylic
- Number of Pins4
- Repeatability (µs)N/A
- Special Feature: Water DetectionNo
- Delay at Power-up (ms)N/A
- Special Feature: Remote TeachNo
- Special Feature: Intrinsically SafeYes
- Output response time (ms)5
- OperationLight/Dark Operate
- Max Op. Temp. (°C)70
- ConnectionIntegral QD
- Min Op. Temp. (°C)-40
- Power Supply/Supply Voltage5-15 V dc
- Max Sensing Distance (mm)5000
- Input/OutputDiscrete
- Primary Housing MaterialThermoplastic
- Quick Disconnect TypeM12 (Euro)
- OutputsConstant Current
- Housing StyleRectangular w/M18 Mount
- Sensing Mode (Detailed)Non-Polarized
- Sensing Mode (General)Retroreflective
- PowerDC
- Sensing BeamVisible Red LED
- Supply voltage (DC)5Vdc-15Vdc (12Vdc nom.)
- Light ColorVisible red
- Response time5ms / 0.005 s
- Order code / Manufacturer SKU34474
- Primary brandBanner Engineering
- ShapeRectangular
- Connection typePre-equipped with 4-pin Euro-style M12 connector
- Materialthermoplastic housing Acrylic lns.
- Sub-range nameMIAD9 NAMUR
- Sensing distance5m
- Mounting modeThreaded mount
- Operating modeLight-ON Dark-ON
- Main functionSensor (Photo-electric)
- Product series / family nameMINI-BEAM series
- Designretro-reflective mode
- Thread sizeM18
- Degree of protectionIP67 NEMA 1 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 NEMA 12 NEMA 13
- Compliant with standard(s)ATEX FM cCSAus CE
- FunctionsPhoto-electric sensor red LED (power ON) potentiometer adjustment
- Digital outputs1 x digital output (NAMUR)
- Ambient air temperature for operation-40...+70 °C
