734-516 WAGO Industrial Automation Components

WAGO 734-516 is a female connector/socket designed for PCB connection with a 16 pole number and supports a nominal voltage of 160V (III/3), 160V (III/2), and 320V (II/2) with a rated impulse voltage of 2.5kV across these categories. It has a rated current of 10A according to IEC/EN 60664-1 standards, and similar ratings are maintained under UL 1059 and CSA approvals for both 300V and 10A in different use groups. The connector features 16 connection points and potentials, with a single connection type and level. It has a pin spacing of 3.81mm, dimensions of 62.46mm in width, 18.5mm in height, and a depth of 10.5mm. The solder pin length is 3.8mm with dimensions of 0.9 x 0.9mm, and it requires a drilled hole diameter of 1.4mm (+0.1). It includes variable coding, anti-rotation protection, and mismating protection but lacks a locking mechanism for the plug-in connection. The mating direction to the PCB is 90 degrees, and it is designed for THT PCB contact with a solder pin arrangement over the entire female connector. The connector is made from Polyamide (PA66) in orange, with a copper alloy contact material and tin plating. It has a flammability class of UL94 V0, weighs 9.7g, and can operate within a temperature range of -60 to +100°C. Packaged in boxes of 25 pieces, it complies with RoHS without exemptions and is identified by GTIN 4045454120436.
