PKG 6Z-3 Turck Cordsets

Turck PKG 6Z-3 PKG 6Z-3 Actuator and Sensor Cordset, Connection Cable
Turck

Part#:PKG 6Z-3

Manufacturer:Turck

Alt. Part#:U0901-26

Product Lifecycle:Active

In-stock parts: 3

Sep 28, 2024

PKG 6Z-3 Actuator and Sensor Cordset, Connection Cable

About the manufacturer: Turck is one of the manufacturers that offers Cordsets that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.

Check out the PKG 6Z-3 Turck price in the box on the right side or send a quick quote.

Product Details

  • Cable length (L)
    3.0  m
  • Current
    2 A
  • Approvals
    UL Listed, CSA, CE, RoHS
  • Cable Jacket Color
    Yellow
  • Cable Jacket Material
    PVC
  • Connector A - Number of Pins
    6
  • Voltage
    125 V
  • Connector A - Style
    Straight, Female
  • Number of Conductors
    6
  • Connector A
    Ø 8 mm
  • Application
    Actuator and Sensor

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

PKG 6Z-3 Description

Turck PKG 6Z-3 is a double-ended cable/cordset designed for various automation applications. It features a 4.2mm cable sheath outer diameter and is capable of handling a rated current of 2A. This part includes a 6-pin M8 picofast female connector with a female snap-lock and a 6-pin M8 picofast male connector with a male snap-lock, both connectors are straight. The cable is part of the M8 picofast sub-range and measures 3 meters in length. It offers a high degree of protection with ratings of IP67, NEMA 1, NEMA 3, NEMA 4, and NEMA 6P, making it suitable for various environmental conditions. The connectors are made of nickel-plated brass with a POM locking sleeve, and the cable jacket is made of TPU, ensuring durability. The cable sheath is black, and the cable is rated for 125Vac. It is a 6-wire cable with a cross-section of 6 x #26AWG.

Related documents PKG 6Z-3 Specs

PKG 6Z-3 edb_U0901-26_eng_us.pdf

This item can ship within 24h!

Manufacturer warranty

$29.90

Stock:

3

Select Qty:

$29.90

$29.90 each

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
