LS-551-1000-LIU22PN8X-H1151 Turck Industrial Automation Components
Part#:LS-551-1000-LIU22PN8X-H1151
Alt. Part#:100015811
Manufacturer:Turck
Category:Industrial Automation Components
Product Lifecycle:Active
Apr 8, 2025
Product description
LS-551-1000-LIU22PN8X-H1151 Turck - LS-551-1000-LIU22PN8X-H1151 Level Sensor, With Analog Output and 2 × Switching Outputs
Product Details
- Weight 1240 g
- RoHS Yes
- Country Of Origin DEU
- HTS Code 9026102040
- Operating Voltage 12 volts, 30 volts
- Weight 1240 grams
- Country of Origin Germany
- Ambient Temperature -20 degrees celsius, 60 degrees celsius
- Communication protocol IO-Link
- Pressure resistance -1…10 bar
- Ambient temperature -20…+60 °C
- Medium temperature -20…+100 °C
- Protection class IP67
- Electrical connection Connector, M12 × 1
- Materials (contact with media) Stainless steel 1.4404 (AISI 316L), PTFE, FKM
- Housing material Plastic, PBT
- Medium liquids
- Current output 4…20 mA
- Voltage output 0…10 V
- Probe length (L) 1000 mm
- Output function NO/NC, PNP/NPN, analog output
- Operating voltage 12…30 VDC
- Process connection G 3/4'' male thread
- Measuring principle Guided microwave
- Detection type medium contact
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of LS-551-1000-LIU22PN8X-H1151 on Powermatic Associates is $706.80. Order now.
About the product
Level Sensor, With Analog Output and 2 × Switching Outputs, , Multiple output signals: one system for both level detection and continuous level monitoring, Low maintenance and quick commissioning without calibration, High flexibility due to cutable probe, Compact, rotatable display housing ensures easy installation, Small inactive areas, ideal for small containers, Process temperature to 212 °F, Process pressure up to 145 psi, Coaxial tubes available for non-metallic tanks, IO-Link 1.1, , 12…30 VDC, 1 × analog output 4… 20 mA/0… 10 V (automatic switchover depending on load), 2 × PNP/IO-Link or PNP/NPN transistor outputs, each switchable, Process connection G3/4 male thread, Probe length 1000 mm, "
