LS-534-0000-LIU24PN8X-H1181 Turck Industrial Automation Components
Part#:LS-534-0000-LIU24PN8X-H1181
Alt. Part#:100001847
Manufacturer:Turck
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
LS-534-0000-LIU24PN8X-H1181 Turck - LS-534-0000-LIU24PN8X-H1181 Level Sensor, With Analog Output and 4 × Switching Outputs
Product Details
- Weight 563 g
- RoHS Yes
- Country Of Origin DEU
- HTS Code 8536507000
- Weight 563 grams
- Operating Voltage 12 volts, 30 volts
- Country of Origin Germany
- Ambient Temperature -20 degrees celsius, 60 degrees celsius
- Housing material Plastic, PBT
- Protection class IP67
- Pressure resistance -1…10 bar
- Electrical connection Connector, M12 × 1
- Ambient temperature -20…+60 °C
- Materials (contact with media) Stainless steel 1.4404 (AISI 316L), PTFE, FKM
- Communication protocol IO-Link
- Voltage output 0…10 V
- Current output 4…20 mA
- Output function NO/NC, PNP/NPN, analog output
- Process connection 3/4” NPT male thread
- Operating voltage 12…30 VDC
- Medium liquids
- Measuring principle Guided microwave
- Detection type medium contact
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of LS-534-0000-LIU24PN8X-H1181 on Powermatic Associates is $706.80. Order now.
About the product
Level Sensor, With Analog Output and 4 × Switching Outputs, , Multiple output signals: one system for both level detection and continuous level monitoring, Low maintenance and quick commissioning without calibration, High flexibility due to cutable probe, Compact, rotatable display housing ensures easy installation, Small inactive areas, ideal for small containers, Process temperature to 212 °F, Process pressure up to 145 psi, Coaxial tubes available for non-metallic tanks, IO-Link 1.1, , 12…30 VDC, 1x analog output 4… 20 mA/0… 10 V (automatic switchover depending on load), 1x transistor output (PNP) or IO-Link, 3x transistor output (PNP/NPN switchable)
