Part#:HGL36150U33X

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Only 2 left in stock. Order Now!

Apr 17, 2025

Product description

Square D by Schneider Electric HGL36150U33X is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HGL sub-range, featuring a PowerPact H-Frame 150 Micrologic 3.2S (LSI) design. It is a 3-pole (3P) device with a rated current of 150A and offers a connection type with lugs on both load and line sides. This unit is designed for individual unit mount on plate, with a net height of 163 mm, width of 104 mm, and depth of 86 mm. It operates with a toggle (manual) mechanism and provides protection functions including Long-time (L), Short-time with fixed time delay (S), and Instantaneous (I) protection. The rated insulation voltage (Ui) is 750 V, with AC rated voltages of 600Vac and 600Y/347Vac, and a DC rated voltage of 500Vdc. The degree of protection is IP40. Protection settings are adjustable for overload (0.3...1 x In), short-circuit with time delay (1.5...10 x lr), and instantaneous short-circuit protection (1.5...15 x In). The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 150 AT, with a frame current rating of 150 AF. Short circuit breaking ratings include 65kA at 240Vac, 35kA at 480Vac and 480Y/277Vac, 18kA at 600Vac and 600Y/347Vac, and 20kA at 250Vdc and 500Vdc, all according to UL489 standards. The trip unit type is an electronic Micrologic Standard 3.2S (LSI) without a display, categorized under Utilisation category A.

Product Details

  • Electrical Connection
    Lugs load Lugs line
  • Width
    4.12 in (104.65 mm)
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Depth
    4.36 in (110.74 mm)
  • Height
    6.4 in (162.56 mm)
  • Continuous Current Rating
    80 %
  • Mounting Mode
    Unit mount
  • Breaking Capacity Code
    G
  • Number Of Poles
    3P
  • Line Rated Current
    150 A
  • Range Of Product
    PowerPact H
  • Product Or Component Type
    Circuit breaker

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
