FSD78-12-D Panduit Electronic Components

Name: FSD78-12-D
Brand: Panduit

Part#:FSD78-12-D

Manufacturer:Panduit

Category:Electronic Components

Product Lifecycle:Active

151 in stock

Mar 14, 2025

Product description

Pan-Term® Single wire ferrule

Product Details

For Use With
CT-1160, CT-1170, CT-1090, CT-1002, CT-1003, CT-1123, CP-991, CTFP-25, CTFP-40, CT-2300/ST (CD-090), CT-2500/L (CT-2523CH)
Part Features
Polypropylene insulation housing conforms to DIN color requirements Meets DIN, UL and CSA standards for single wire containment Funnel entry for faster insertion and lower installed cost Designed with a seamless barrel to contain loose wire strands for
Sub Brand
Pan-Term®
Base Material
Copper
Color Code
Black
Overall Length (In.)
0.73
Overall Length (mm)
18.5
Packaging Type
Loose Piece Ferrules
Standards Met
DIN 46228, CSA C22.2 No. 291-14, UL 486F
Product Type
Single wire ferrule
Finish/Coating
Tin-Plated
Maximum Wire Insulation Diameter (In.)
0.12
Inside Diameter (mm)
1.8
Minimum Operating Temperature (°C)
-54
Minimum Operating Temperature (°F)
-60
Maximum Wire Insulation Diameter (mm)
3
Maximum Operating Temperature (°C)
105
Maximum Operating Temperature (°F)
221
Pin Length (mm)
12
Wire Strip Length (mm)
15.9

Inside Diameter (In.)

0.07

Pin Length (In.)

0.47

Flammability Rating

UL94-HB

Minimum Metric Conductor Size (mm²)

1.5

Wire Strip Length (In.)

5/8

Copper Conductor Size (AWG)

Maximum Metric Conductor Size (mm²)

1.5

Ferrule Type

Single Wire Standard

Cover Material

Polypropylene

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
