EV10-8RB-Q Panduit Electronic Components
Part#:EV10-8RB-Q
Manufacturer:Panduit
Category:Electronic Components
Product Lifecycle:Active
Mar 15, 2025
Product description
StrongHold EV10-8RB-Q Vinyl Insulated Ring Terminal
Product Details
- Overall Width (In.) 0.31
- Product Type Ring Terminal
- For use with CT-100A, CT-200, CT-600-A (CT-570CH) CT-1570, CT-1701, CT-2500(CT-2570CH), CT-160, CT-260
- Tongue Width (In.) 0.58
- Tongue Thickness (mm) 1
- Overall Length (mm) 26.7
- Tongue Length (mm) 13.3
- Overall Width (mm) 7.9
- Minimum Wire Insulation Diameter (mm) 4.3
- Maximum Wire Insulation Diameter (mm) 5.8
- Maximum Wire Insulation Diameter (In.) 0.23
- Maximum Operating Temperature (°C) 105
- Minimum Copper Conductor Size (AWG) #12
- Packaging Type Bag
- Tongue Width (mm) 14.7
- Tongue Length (In.) 0.53
- Tongue Thickness (In.) 0.04
- Sub Brand StrongHold™
- Overall Length (In.) 1.05
- Outer Diameter (mm) 7.9
- Outer Diameter (In.) 0.31
- Minimum Wire Insulation Diameter (In.) 0.17
- Maximum Operating Temperature (°F) 221
- Insulation Diameter (In.) 0.23
- Insulation Diameter (mm) 5.8
- Barrel Length (In.) 0.45
- Flammability Rating UL587-H
- Barrel Length (mm) 11.3
- Barrel Type Funnel
- Color Code Yellow
- Finish/Coating Tin-Plated
- Maximum Voltage (kV) 0.6
- Maximum Voltage (V) 600
- Base Material Copper
- Wire Strip Length (mm) 7.9
- Standards Met UL Listed 587H E52164; CSA Certified LR31212
- Wire Strip Length (In.) 0.31
- Minimum Metric Conductor Size (mm²) 1.5
- Minimum Copper Conductor Size (AWG STR) #12
- Minimum Copper Conductor Size (AWG SOL) #12
- Maximum Metric Conductor Size (mm²) 6
- Minimum Operating Temperature (°C) 105
- Maximum Copper Conductor Size (AWG SOL) #10
- Insulation Material Vinyl
- Maximum Wire Size (AWG) #10
- Minimum Operating Temperature (°F) 221
- Stud Hole Size (mm) 4
- Maximum Copper Conductor Size (AWG) #10
- Maximum Copper Conductor Size (AWG STR) #10
- Stud Hole Size (In.) 3/20
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
