P10-8R-L Panduit Electronic Components

Product Details

• For Use With
  CT-100A, CT-200, CT-600-A (CT-570CH) CT-1570, CT-1701, CT-2500(CT-2570CH), CT-160, CT-260
• Part Features
  • Ring tongue design assures a secure connection in high vibration applications • Internal barrel serrations assure good wire contact and maximum tensile strength
• Packaging Type
  Box
• Overall Length (mm)
  19.8
• Tongue Length (In.)
  0.08
• Tongue Thickness (mm)
  1
• Tongue Width (mm)
  7.9
• Tongue Width (In.)
  0.31
• Overall Width (In.)
  0.31
• Tongue Length (mm)
  2
• Overall Width (mm)
  7.9
• Tongue Thickness (In.)
  0.04
• Product Type
  Ring Terminal
• Inside Diameter (mm)
  3.3
• Overall Length (In.)
  0.78
• Minimum Wire Insulation Diameter (mm)
  4.3
• Inside Diameter (In.)
  0.13
• Sub Brand
  Pan-Term
• Maximum Operating Temperature (°F)
  302
• Outer Diameter (mm)
  7.9
Outer Diameter (In.)
0.31
Minimum Wire Insulation Diameter (In.)
0.17
Maximum Operating Temperature (°C)
150
Insulation Diameter (mm)
5.6
Insulation Diameter (In.)
0.22
Flammability Rating
UL 587-H
Barrel Length (In.)
0.31
Barrel Length (mm)
7.9
Color Code
Silver
Finish/Coating
Tin-Plated
Maximum Voltage (kV)
2
Maximum Voltage (V)
2000
Maximum Metric Conductor Size (mm²)
6
Wire Strip Length (In.)
0.28
Minimum Copper Conductor Size (AWG)
#14
Minimum Copper Conductor Size (AWG STR)
#14
Minimum Copper Conductor Size (AWG SOL)
#14
Maximum Wire Size (AWG)
#10
Base Material
Copper
Standards Met
UL Listed 587H E52164; CSA Certified LR31212
Wire Strip Length (mm)
7.1
Maximum Copper Conductor Size (AWG SOL)
#10
Minimum Operating Temperature (°F)
302
Minimum Operating Temperature (°C)
150
Stud Size
#8
Stud Hole Size (mm)
4
Maximum Copper Conductor Size (AWG)
#10
Maximum Copper Conductor Size (AWG STR)
#10
Insulation Material
Non-Insulated
Stud Hole Size (In.)
4/25
