FSD77-10-D Panduit Industrial Automation Components

FSD77-10-D on Powermatic Associates
Panduit

Part#:FSD77-10-D

Manufacturer:Panduit

Category:Industrial Automation Components

Product Lifecycle:Active

28 in stock

Apr 13, 2025

Product description

VINYL INSULATED FERRULE .65"18 AWG SINGLE WIRE ENDRED ROHS

Product Details

  • Part Features
    Polypropylene insulation housing conforms to DIN color requirements Meets DIN, UL and CSA standards for single wire containment Funnel entry for faster insertion and lower installed cost Designed with a seamless barrel to contain loose wire strands for
  • Sub Brand
    Pan-Term®
  • Color Code
    Red
  • Base Material
    Copper
  • Packaging Type
    Loose Piece Ferrules
  • For Use With
    CT-1160, CT-1170, CT-1090, CT-1002, CT-1003, CT-1123, CP-991, CTFP-25, CTFP-40, CT-2300/ST (CD-090), CT-2500/L (CT-2523CH)
  • Finish/Coating
    Tin-Plated
  • Standards Met
    DIN 46228, CSA C22.2 No. 291-14, UL 486F
  • Product Type
    Single wire ferrule
  • Overall Length (In.)
    0.65
  • Overall Length (mm)
    16.5
  • Maximum Wire Insulation Diameter (In.)
    0.12
  • Inside Diameter (In.)
    0.06
  • Maximum Wire Insulation Diameter (mm)
    3
  • Minimum Operating Temperature (°F)
    -60
  • Maximum Operating Temperature (°F)
    221
  • Minimum Operating Temperature (°C)
    -54
  • Maximum Operating Temperature (°C)
    105
  • Inside Diameter (mm)
    1.5
  • Pin Length (In.)
    0.39
  • Wire Strip Length (mm)
    13.5
  • Pin Length (mm)
    10
  • Wire Strip Length (In.)
    17/32
  • Flammability Rating
    UL94-HB
  • Cover Material
    Polypropylene
  • Minimum Metric Conductor Size (mm²)
    1
  • Maximum Metric Conductor Size (mm²)
    1
  • Ferrule Type
    Single Wire Standard

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
