FSD77-12-D Panduit Electronic Components

FSD77-12-D on Powermatic Associates
Panduit

Part#:FSD77-12-D

Manufacturer:Panduit

Category:Electronic Components

Product Lifecycle:Active

55 in stock

Mar 14, 2025

Product description

Pan-Term® Single wire ferrule

Product Details

  • Part Features
    Polypropylene insulation housing conforms to DIN color requirements Meets DIN, UL and CSA standards for single wire containment Funnel entry for faster insertion and lower installed cost Designed with a seamless barrel to contain loose wire strands for
  • Sub Brand
    Pan-Term®
  • Color Code
    Red
  • Packaging Type
    Loose Piece Ferrules
  • Standards Met
    DIN 46228, CSA C22.2 No. 291-14, UL 486F
  • For Use With
    CT-1160, CT-1170, CT-1090, CT-1002, CT-1003, CT-1123, CP-991, CTFP-25, CTFP-40, CT-2300/ST (CD-090), CT-2500/L (CT-2523CH)
  • Finish/Coating
    Tin-Plated
  • Base Material
    Copper
  • Maximum Wire Insulation Diameter (In.)
    0.12
  • Maximum Wire Insulation Diameter (mm)
    3
  • Product Type
    Single wire ferrule
  • Inside Diameter (In.)
    0.06
  • Overall Length (mm)
    18.5
  • Overall Length (In.)
    0.73
  • Minimum Operating Temperature (°F)
    -60
  • Minimum Operating Temperature (°C)
    -54
  • Maximum Operating Temperature (°F)
    221
  • Maximum Operating Temperature (°C)
    105
  • Inside Diameter (mm)
    1.5
  • Pin Length (mm)
    12
  • Ferrule Type
    Single Wire Standard
  • Cover Material
    Polypropylene
  • Maximum Metric Conductor Size (mm²)
    1
  • Wire Strip Length (In.)
    5/8
  • Minimum Metric Conductor Size (mm²)
    1
  • Flammability Rating
    UL94-HB
  • Pin Length (In.)
    0.47
  • Wire Strip Length (mm)
    15.9

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.



Manufacturer warranty
