P14-14R-C Panduit Industrial Automation Components

Product Details

• Type:
  Standard
• Stud Size:
  1/4 Inch
• Temperature:
  302 Deg F
• Series:
  P-R
• Minimum Conductor Size:
  18 AWG
• Standard Package:
  100 per Pack
• Shipping Length:
  4.00 In.
• Shipping Weight:
  0.30 lbs.
• Shipping Height:
  2.00 In.
• Approval:
  UL 486A/B
• Insulation Type:
  Non-Insulated
• UPC:
  07498380222
• Maximum Conductor Size:
  14 AWG
• Shipping Width:
  2.00 In.
• Part Features
  • Ring tongue design assures a secure connection in high vibration applications • Internal barrel serrations assure good wire contact and maximum tensile strength
• Tongue Thickness (mm)
  0.8
• Tongue Width (mm)
  11.7
• Tongue Width (In.)
  0.46
• For Use With
  CT-100, CT-200, CT-1570, CT-2300/ST (CD-570), CT-2500/L (CT-2570CH), & UP14ZLW (CD-570)
• Product Type
  Loose Piece Ring Terminal
Packaging Type
Bottle
Overall Width (mm)
11.7
Tongue Thickness (In.)
0.03
Overall Width (In.)
0.46
Overall Length (mm)
23.1
Sub Brand
Pan-Term®
Overall Length (In.)
0.91
Inside Diameter (In.)
0.09
Inside Diameter (mm)
2.3
Outer Diameter (mm)
4.06
Seam Type
Brazed
Outer Diameter (In.)
0.16
Maximum Operating Temperature (°F)
302
Maximum Operating Temperature (°C)
150
Barrel Type
Standard
Maximum Voltage (kV)
2
Standards Met
UL 486A/B, and CSA 22.2 No.65
Finish/Coating
Tin-Plated
Base Material
Copper
Maximum Voltage (V)
2000
Wire Strip Length (mm)
7.1
Minimum Copper Conductor Size (AWG STR)
#18
Stud Hole Size (In.)
1/4
Wire Strip Length (In.)
9/32
Minimum Metric Conductor Size (mm²)
1
Maximum Metric Conductor Size (mm²)
2.5
Minimum Copper Conductor Size (AWG SOL)
#18
Maximum Copper Conductor Size (AWG SOL)
#14
Maximum Copper Conductor Size (AWG STR)
#14
Insulation Material
Non-Insulated
