FSD75-10-D Panduit Electronic Components

Product Details

• Part Features
  Polypropylene insulation housing conforms to DIN color requirements Meets DIN, UL and CSA standards for single wire containment Funnel entry for faster insertion and lower installed cost Designed with a seamless barrel to contain loose wire strands for
• Color Code
  White
• Sub Brand
  Pan-Term®
• Base Material
  Copper
• Packaging Type
  Loose Piece Ferrules
• For Use With
  CT-1160, CT-1170, CT-1090, CT-1002, CT-1003, CT-1123, CP-991, CTFP-25, CTFP-40, CT-2300/ST (CD-090), CT-2500/L (CT-2523CH)
• Finish/Coating
  Tin-Plated
• Product Type
  Single wire ferrule
• Overall Length (mm)
  15.5
• Standards Met
  DIN 46228, CSA C22.2 No. 291-14, UL 486F
• Overall Length (In.)
  0.61
• Maximum Wire Insulation Diameter (mm)
  2.5
• Maximum Wire Insulation Diameter (In.)
  0.09
• Minimum Operating Temperature (°F)
  -60
• Minimum Operating Temperature (°C)
  -54
• Maximum Operating Temperature (°F)
  221
• Maximum Operating Temperature (°C)
  105
• Pin Length (In.)
  0.39
• Inside Diameter (mm)
  1.1
• Inside Diameter (In.)
  0.04
Pin Length (mm)
10
Flammability Rating
UL94-HB
Minimum Metric Conductor Size (mm²)
0.5
Wire Strip Length (mm)
13.5
Ferrule Type
Single Wire Standard
Wire Strip Length (In.)
17/32
Maximum Metric Conductor Size (mm²)
0.5
Cover Material
Polypropylene
Copper Conductor Size (AWG)
22 - 20
Note
UL with 20 AWG wire only
