8040568 Festo Directional Control Valves

Product Details

• Sealing principle
  Soft
• Valve function
  3/2, closed, monostable
• Pneumatic working port
  Sub-base, size 15 mm as per ISO 15218
• Symbol
  00991308
• Duty cycle
  100%
• CE marking (see declaration of conformity)
  As per EU low voltage directive
• Ambient temperature
  -5 °C ... 50 °C
• Note on materials
  RoHS-compliant
• Actuation type
  Electrical
• Standard nominal flow rate
  13.5 l/min
• Reset method
  Mechanical spring
• Manual override
  Non-detenting
• Switching time off
  35 ms
• Permissible voltage fluctuations
  +/- 10 %
• Shock resistance
  Shock test with severity level 1 as per FN 942017-5 and EN 60068-2-27
• Pneumatic connection 2
  Sub-base
• Width
  15 mm
• Operating pressure
  1.5 bar ... 8 bar
• Mounting position
  Any
• Flow direction
  Non-reversible
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Pneumatic connection 1
Sub-base
Lap
Underlap
Operating voltage
230V AC
Type code
VSCS
Type of control
Direct
On switching time
8 ms
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Temperature of medium
-5 °C ... 50 °C
Pneumatic connection 3
Sub-base
Degree of protection
IP65
Conforms to standard
ISO 15218
Note on forced dynamization
Switching frequency at least once a week
Coil characteristics
230 V AC: 50/60 Hz, initial power 1.9 VA, holding power 1.3 VA
Vibration resistance
Transport application test with severity level 1 as per FN 942017-4 and EN 60068-2-6
Electrical connection
Form C as per DIN EN 175301-803
Seals material
NBR
