19137 Festo Directional Control Valves
Part#:19137
Alt. Part#:JMVH-5-1/4-S-B
Manufacturer:Festo
Category:Directional Control Valves
Product Lifecycle:Active
Product description
solenoid valve JMVH-5-1/4-S-B With solenoid coils and manual override, without plug sockets. Valve function: 5/2 bistable, Type of actuation: electrical, Width: 32 mm, Standard nominal flow rate: 1600 l/min, Operating pressure: -0,9 - 10 bar
Product Details
- Lap Overlap
- Pneumatic working port G1/4
- Type code JMVH
- Type of control Pilot-controlled
- Pilot pressure 2 bar ... 10 bar
- Coil characteristics 24 V DC: 2.5 W
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Valve function 5/2, bistable
- Standard nominal flow rate 1600 l/min
- Width dimension 33 mm
- Sealing principle Soft
- Symbol 00991016
- Max. positive test pulse with 0 signal 2200 µs
- C value 6.35 l/sbar
- Permissible voltage fluctuations +/- 10 %
- Temperature of medium -5 °C ... 50 °C
- Product weight 615 g
- Pilot exhaust air port 84 M5
- Pneumatic connection 1 G1/4
- Note on materials RoHS-compliant
- Width 32 mm
- Operating pressure -0.9 bar ... 10 bar
- Exhaust air function With flow control option
- Manual override Non-detenting
- Flow direction Reversible
- Changeover time 16 ms
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Ambient temperature -5 °C ... 50 °C
- Auxiliary pilot air port 14 G1/8
- Pneumatic connection 4 G1/4
- Design Piston gate valve
- Mounting position Any
- b-value 0.38
- Max. negative test pulse on 1 signal 3700 µs
- Type of mounting Optionally: With through-hole
- Pilot air port 12 G1/8
- Pneumatic connection 2 G¼
- Seals material NBR
- Actuation type Electrical
- Nominal width 10 mm
- Pilot air supply port External
- Max. switching frequency 3 Hz
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Storage temperature -40 °C ... 60 °C
- Pilot exhaust air port 82 M5
- Pneumatic connection 3 G1/4
- Housing material Die-cast aluminum
- Pilot medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Auxiliary pilot air port 12 G1/8
- Pilot air port 14 G1/8
- Pneumatic connection 5 G1/4
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
