186096 Festo Pneumatic Fittings
Part#:186096
Alt. Part#:QS-G1/8-6
Manufacturer:Festo
Category:Pneumatic Fittings
Product Lifecycle:Active
Mar 15, 2025
Product description
push-in fitting QS-G1/8-6 male thread with external hexagon. Size: Standard, Nominal size: 5 mm, Type of seal on screw-in stud: Sealing ring, Assembly position: Any, Container size: 10
Product Details
- Nominal width 5 mm
- Size Standard
- Operating pressure for entire temperature range -0.95 bar ... 6 bar
- Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
- Tolerance for nominal tightening torque ± 20%
- Releasing ring color Blue
- Maritime classification See certificate
- Type of seal on screwed trunnion Sealing ring
- Information on operating and pilot media Operation with oil lubrication possible
- Product weight 8.3 g
- Note on materials RoHS-compliant
- Design Push-pull principle
- Ambient temperature -10 °C ... 80 °C
- Pneumatic connection 1 External thread G1/8
- Releasing ring material POM
- Material of tubing seal NBR
- Type code QS
- Mounting position Any
- Pack size 10
- Nominal tightening torque 7 Nm
- Material of tube retaining claw High-alloy stainless steel
- Temperature-dependent operating pressure -0.95 bar ... 14 bar
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Pneumatic connection 2 for pneumatic tubing outside diameter 6 mm
- Housing material Brass Nickel-plated
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
186096 Related Documents
Manufacturer warranty
186096 Festo
Get a quick Quote!
Request a quote, and we will send you price within minutes.
Stock:
Select Qty:
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare 186096 with other products
Nominal width
Size
Operating pressure for en...
Operating medium
Tolerance for nominal tig...
Releasing ring color
Maritime classification
Type of seal on screwed t...
Information on operating ...
Product weight
Note on materials
Design
Ambient temperature
Pneumatic connection 1
Releasing ring material
Material of tubing seal
Type code
Mounting position
Pack size
Nominal tightening torque
Material of tube retainin...
Temperature-dependent ope...
Corrosion resistance clas...
Pneumatic connection 2
Housing material
Selected product
186096
Festo
push-in fitting QS-G1/8-6 male thread with external hexagon. Size: Standard, Nominal size: 5 mm, Typ...
Nominal width5 mm
SizeStandard
Operating pressure for entire temperature range-0.95 bar ... 6 bar
Operating mediumCompressed air as per ISO 85...
Tolerance for nominal tightening torque± 20%
Releasing ring colorBlue
Maritime classificationSee certificate
Type of seal on screwed trunnionSealing ring
Information on operating and pilot mediaOperation with oil lubricati...
Product weight8.3 g
Note on materialsRoHS-compliant
DesignPush-pull principle
Ambient temperature-10 °C ... 80 °C
Pneumatic connection 1External thread G1/8
Releasing ring materialPOM
Material of tubing sealNBR
Type codeQS
Mounting positionAny
Pack size10
Nominal tightening torque7 Nm
Material of tube retaining clawHigh-alloy stainless steel
Temperature-dependent operating pressure-0.95 bar ... 14 bar
Corrosion resistance class (CRC)1 - Low corrosion stress
Pneumatic connection 2for pneumatic tubing outside...
Housing materialBrass Nickel-plated
186095
Festo
push-in fitting QS-G1/8-4 male thread with external hexagon. Size: Standard, Nominal size: 3 mm, Typ...
Nominal width3 mm
SizeStandard
Operating pressure for entire temperature range-0.95 bar ... 6 bar
Operating mediumCompressed air as per ISO 85...
Tolerance for nominal tightening torque± 20%
Releasing ring colorBlue
Maritime classificationSee certificate
Type of seal on screwed trunnionSealing ring
Information on operating and pilot mediaOperation with oil lubricati...
Product weight9.1 g
Note on materialsRoHS-compliant
DesignPush-pull principle
Ambient temperature-10 °C ... 80 °C
Pneumatic connection 1External thread G1/8
Releasing ring materialPOM
Material of tubing sealNBR
Type codeQS
Mounting positionAny
Pack size10
Nominal tightening torque7 Nm
Material of tube retaining clawHigh-alloy stainless steel
Temperature-dependent operating pressure-0.95 bar ... 14 bar
Corrosion resistance class (CRC)1 - Low corrosion stress
Pneumatic connection 2for pneumatic tubing outside...
Housing materialBrass Nickel-plated
186109
Festo
push-in fitting QS-G1/8-8-I male thread with internal hexagon socket. Size: Standard, Nominal size: ...
Nominal width5.3 mm
SizeStandard
Operating pressure for entire temperature range-0.95 bar ... 6 bar
Operating mediumCompressed air as per ISO 85...
Tolerance for nominal tightening torque± 20%
Releasing ring colorBlue
Maritime classificationSee certificate
Type of seal on screwed trunnionSealing ring
Information on operating and pilot mediaOperation with oil lubricati...
Product weight12 g
Note on materialsRoHS-compliant
DesignPush-pull principle
Ambient temperature-10 °C ... 80 °C
Pneumatic connection 1External thread G1/8
Releasing ring materialPOM
Material of tubing sealNBR
Type codeQS
Mounting positionAny
Pack size10
Nominal tightening torque7 Nm
Material of tube retaining clawHigh-alloy stainless steel
Temperature-dependent operating pressure-0.95 bar ... 14 bar
Corrosion resistance class (CRC)1 - Low corrosion stress
Pneumatic connection 2for pneumatic tubing outside...
Housing materialBrass Nickel-plated
About the manufacturer
Powermatic Associates is an authorized Festo distributor, proudly offering a wide array of Festo's innovative industrial automation products and solutions. Festo is a globally recognized leader in automation technology and pneumatic solutions, renowned for their commitment to quality, efficiency, and sustainability. With a vast portfolio ranging from actuators, valves, sensors, and connectors to electric drives and complete automation systems, Festo ensures that industries can achieve seamless operations and enhanced productivity. As specialists in motion and control technologies, Powermatic Associates supplies Festo's advanced pneumatics and electromechanical systems, designed to meet the rigorous demands of modern manufacturing environments. Festo's pneumatic cylinders and actuators are engineered for precision and reliability, providing optimal performance in a variety of applications, from simple handling tasks to complex automation processes. Festo's cutting-edge sensors and control units further complement these systems by delivering accurate data and enabling sophisticated process control, which are essential for smart factory initiatives. Moreover, Festo excels in modular automation solutions, allowing businesses to customize systems tailored specifically to their operational needs. Their energy-efficient pneumatic components and electric automation solutions are designed to reduce energy consumption and contribute to sustainable manufacturing practices. By integrating Festo’s products into their facilities, customers can streamline production processes, minimize downtime, and elevate overall operational efficiency. Powermatic Associates complements Festo's product range with our extensive value-added services, including expert engineering support and customized automation solutions. Our partnership with Festo allows us to provide superior technical assistance and rapid delivery from our well-stocked inventory. Whether you need precise fluid control, reliable actuation, or comprehensive system integration, Powermatic Associates and Festo together offer unparalleled service and solutions. Trust in our collaboration to harness the latest advancements in automation technology, ensuring your projects remain on track and your business achieves maximum profitability. Through this strategic partnership, Powermatic Associates and Festo empower industries to embrace innovation and maintain a competitive edge in the fast-evolving industrial landscape, driving forward efficiency, productivity, and sustainability.
About the Product Category
Air fittings, also referred to as pneumatic fittings or connectors, are crucial components of pneumatic systems. They ensure safe and airtight connections between various pneumatic elements like air hoses, tubes, valves, and cylinders.
Recently viewed products
Relevant products
FAQ
164 in stock
push-in fitting QS-G1/8-6 male thread with external hexagon. Size: Standard, Nominal size: 5 mm, Type of seal on screw-in stud: Sealing ring, Assembly position: Any, Container size: 10
