564817 Festo Pneumatic Fittings

564817 on Powermatic Associates
Festo

Part#:564817

Alt. Part#:QB-3/8H-1/4-U

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

9 in stock

Mar 31, 2025

Product description

push-in connector QB-3/8H-1/4-U male thread with external hexagon. Size: Standard, Nominal size: 0,22 ", Assembly position: Any, Design structure: Push/pull principle, Operating pressure complete temperature range: -13,8 - 145 Psi

Product Details

  • Type code
    QB
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Product weight
    4.706 g
  • Releasing ring material
    POM
  • Material of tube retaining claw
    High-alloy stainless steel
  • Nominal width
    5.588 mm
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Pneumatic connection 1
    For pneumatic tubing outside diameter 1/4"
  • Mounting position
    Any
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Releasing ring color
    Gray
  • Pneumatic connection 2
    for pneumatic tubing outside diameter 3/8"
  • Design
    Push-pull principle
  • Temperature-dependent operating pressure
    -0.951 bar ... 9.997 bar
  • Housing material
    PBT
  • Size
    Standard
  • Operating pressure for entire temperature range
    -0.951 bar ... 9.997 bar
  • Ambient temperature
    0 °C ... 60 °C
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant
  • Material of tubing seal
    NBR

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.



564817 Related Documents

Manufacturer warranty

564817 Festo

Get a quick Quote!

Request a quote, and we will send you price within minutes.

Stock:

9

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery


Secure Payment Processing


Warranty


Responsive Customer Support

Got Questions? We've Got Answers!


Need more details?

Feel free to chat with us

Compare 564817 with other Pneumatic Fittings products

Type code

Information on operating ...

Product weight

Releasing ring material

Material of tube retainin...

Nominal width

Corrosion resistance clas...

Pneumatic connection 1

Mounting position

Operating medium

Selected product

564817
9 in stock
564817
Festo

push-in connector QB-3/8H-1/4-U male thread with external hexagon. Size: Standard, Nominal size: 0,2...

Type codeQB

Information on operating and pilot mediaOperation with oil lubricati...

Product weight4.706 g

Releasing ring materialPOM

Material of tube retaining clawHigh-alloy stainless steel

Nominal width5.588 mm

Corrosion resistance class (CRC)1 - Low corrosion stress

Pneumatic connection 1For pneumatic tubing outside...

Mounting positionAny

Operating mediumCompressed air as per ISO 85...

564816
