564809 Festo Pneumatic Fittings
Part#:564809
Alt. Part#:QBT-1/2T-3/8-U
Manufacturer:Festo
Category:Pneumatic Fittings
Product Lifecycle:Active
Mar 15, 2025
Product description
push-in T-connector QBT-1/2T-3/8-U reducing. Size: Standard, Nominal size: 0,315 ", Assembly position: Any, Design structure: Push/pull principle, Operating pressure complete temperature range: -13,8 - 145 Psi
Product Details
- Mounting position Any
- Operating pressure for entire temperature range -0.951 bar ... 9.997 bar
- Pneumatic connection 1 For pneumatic tubing outside diameter 1/2"
- Releasing ring material POM
- Nominal width 8.001 mm
- Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-]
- Product weight 25.203 g
- Housing material PBT
- Type code QBT
- Temperature-dependent operating pressure -0.951 bar ... 9.997 bar
- Ambient temperature 0 °C ... 60 °C
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Size Standard
- Information on operating and pilot media Operation with oil lubrication possible
- Pneumatic connection 2 for pneumatic tubing outside diameter 3/8"
- Material of tube retaining claw High-alloy stainless steel
- Design Push-pull principle
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Releasing ring color Gray
- Material of tubing seal NBR
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
