572311 Festo Pneumatic Fittings

Product Details

• Nominal width
  2.388 mm
• Type of seal on screwed trunnion
  Sealing ring
• Ambient temperature
  0 °C ... 60 °C
• Pneumatic connection 1
  External thread 10-32 UNF-2A
• Type code
  QBM
• Corrosion resistance class (CRC)
  1 - Low corrosion stress
• Releasing ring color
  Gray
• Material of tubing seal
  NBR
• Operating pressure for entire temperature range
  -0.951 bar ... 9.997 bar
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:-:-]
• Max. tightening torque
  1.5 Nm
• Housing material
  Brass, nickel-plated PBT
• Material of tube retaining claw
  High-alloy stainless steel
• Design
  Push-pull principle
• Temperature-dependent operating pressure
  -0.951 bar ... 9.997 bar
• Pneumatic connection 2
  for pneumatic tubing outside diameter 1/8"
• Note on materials
  Contains paint-wetting impairment substances RoHS-compliant
• Size
  Mini
• Mounting position
  Any
• Information on operating and pilot media
  Operation with oil lubrication possible
Product weight
2.013 g
Releasing ring material
POM
