153134 Festo Pneumatic Fittings

153134 on Powermatic Associates
Festo

Part#:153134

Alt. Part#:QST-6-4

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

8 in stock

Apr 6, 2025

Product description

push-in T-connector QST-6-4 reducing. Size: Standard, Nominal size: 2,3 mm, Assembly position: Any, Container size: 10, Design structure: Push/pull principle

Product Details

  • Maritime classification
    See certificate
  • Design
    Push-pull principle
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Pneumatic connection 1
    For pneumatic tubing outside diameter 6 mm
  • Housing material
    PBT
  • Material of tubing seal
    NBR
  • Nominal width
    2.3 mm
  • Operating pressure for entire temperature range
    -0.95 bar ... 6 bar
  • Ambient temperature
    -10 °C ... 80 °C
  • No. of supply lines
    1
  • Releasing ring color
    Blue
  • Size
    Standard
  • Mounting position
    Any
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • No. of outlets
    2
  • Releasing ring material
    POM
  • Type code
    QST
  • Temperature-dependent operating pressure
    -0.95 bar ... 14 bar
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
  • Pneumatic connection 2
    for pneumatic tubing outside diameter 4 mm
  • Material of tube retaining claw
    High-alloy stainless steel
  • Pack size
    10
  • Product weight
    11 g
  • Note on materials
    RoHS-compliant

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
