153164 Festo Pneumatic Fittings

153164 on Powermatic Associates
Festo

Part#:153164

Alt. Part#:QSSF-1/4-6-B

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

7 in stock

Apr 29, 2025

Product description

push-in bulkhead fitting QSSF-1/4-6-B with female thread. Size: Standard, Nominal size: 5 mm, Assembly position: Any, Container size: 10, Design structure: Push/pull principle

Product Details

  • Type code
    QSSF
  • Temperature-dependent operating pressure
    -0.95 bar ... 14 bar
  • Ambient temperature
    -10 °C ... 80 °C
  • Note on materials
    RoHS-compliant
  • Nominal width
    5 mm
  • Operating pressure for entire temperature range
    -0.95 bar ... 6 bar
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Pneumatic connection 1
    Internal thread G1/4
  • Releasing ring material
    POM
  • Maritime classification
    See certificate
  • Design
    Push-pull principle
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Product weight
    27 g
  • Releasing ring color
    Blue
  • Material of tubing seal
    NBR
  • Pack size
    10
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
  • Pneumatic connection 2
    for pneumatic tubing outside diameter 6 mm
  • Housing material
    Brass Nickel-plated
  • Material of tube retaining claw
    High-alloy stainless steel
  • Size
    Standard
  • Mounting position
    Any

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
