178295 Festo Proximity Sensors

178295 on Powermatic Associates
Festo

Part#:178295

Alt. Part#:SIES-Q8B-PS-S-L

Manufacturer:Festo

Category:Proximity Sensors

Product Lifecycle:Active

Product description

proximity sensor SIES-Q8B-PS-S-L Inductive, with plug, can be flush-mounted, normally-open function, positive-switching. Conforms to standard: EN 60947-5-2, Authorisation: (* RCM Mark, * c UL us - Listed (OL)), CE mark (see declaration of conformity): to

Product Details

  • Conforms to standard
    EN 60947-5-2
  • Assured operating distance
    1.2 mm
  • Switching element function
    N/O contact
  • Voltage drop
    2 V
  • Idle current
    ≤ 10 mA
  • Type of mounting
    With internal thread
  • Housing material
    Die-cast zinc Nickel-plated
  • Type code
    SIES
  • Rated operating distance
    1.5 mm
  • Switching output
    PNP
  • DC operating voltage range
    10 V ... 30 V
  • Electrical connection
    3-pin Plug
  • Mounting type
    Flush
  • Electrical output
    PNP
  • Certification
    RCM compliance mark c UL us - Listed (OL)
  • Note on materials
    Free of copper and PTFE RoHS-compliant
  • Max. switching frequency DC
    1500 Hz
  • Max. switching frequency
    3500 Hz
  • Size
    8x8x59 mm
  • Product weight
    12 g
  • Switching status indication
    LED yellow
  • Symbol
    00991701
  • Reduction factors
    Aluminum = 0.45 Steel St 37 = 1.0
  • Ambient temperature
    -25 °C ... 70 °C
  • Short-circuit protection
    Pulsed
  • Reverse polarity protection
    for all electrical connections
  • Residual ripple
    10 %
  • Selection of additional sensor information
    Special design
  • CE marking (see declaration of conformity)
    As per EU EMC directive
  • Repetition accuracy
    0.07 mm
  • Max. output current
    200 mA
  • Degree of protection
    IP67
  • Selection of sensor version
    Standard

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
