Q45XB6RQ Banner Proximity Sensors
Part#:Q45XB6RQ
Alt. Part#:37880
Manufacturer:Banner
Category:Proximity Sensors
Product Lifecycle:Active
Product description
Q45X Series: Receiver; Range: 60 m; Input: depends on Bus Card; Output: depends on Bus Card used; Mini 5-pin Integral QD
Product Details
- Weight 263.08336 g
- Country Of Origin US
- Product series / family name Q series
- Light Color Infrared (IR)
- Compliant with standard(s) cCSAus
- Sub-range name Q45X
- Functions Photo-electric sensor receiver green LED (power ON) red LED (signal) yellow LED (output state) potentiometer adjustment
- Mounting mode Threaded mount
- Operating mode Light-ON Dark-ON
- Main function Sensor (Photo-electric)
- Design through-beam system / opposed mode
- Shape Rectangular
- Response time 2ms / 0.002 s
- Order code / Manufacturer SKU 37880
- Sensing distance 60m
- Thread size M30
- Degree of protection IP67 NEMA 6P
- Material thermoplastic housing Acrylic lns.
- Primary brand Banner Engineering
- Supply voltage (DC) 10Vdc-30Vdc (12Vdc / 24Vdc nom.)
- Wavelength 880 nm
- Connection type Pre-equipped with 5-pin 7/8" Mini connector
- Digital outputs 1 x digital output (PNP/NPN transistor)
- Ambient air temperature for operation -40...+70 °C
- Power DC
- Sensing Beam Infrared LED
- Max Sensing Distance (mm) 60000
- Quick Disconnect Type 7/8 in. (Mini)
- Operation Light/Dark Operate
- Max Op. Temp. (°C) 70
- Sensing Beam Wavelength 880
- IP Rating IP67
- Repeatability (µs) 250
- NEMA Rating NEMA 6P
- Barrel Diameter (mm) 30
- Feature: Encapsulated No
- Feature: Audible No
- Sensing Mode (General) Opposed
- Housing Style Rectangular
- Sensing Mode (Detailed) Receiver
- Min Op. Temp. (°C) -40
- Delay at Power-up (ms) 100
- Max Op. Relative Humidity [%] 90% @ 50°C
- IO Link No
- Primary Housing Material Thermoplastic
- Power Supply/Supply Voltage 10-30 V dc
- Special Feature: Water Detection No
- Indicator LEDs
- Outputs Bipolar (NPN & PNP)
- Output response time (ms) 2 ON/1 OFF
- Number of Pins 5
- Opposed Mode Emitter/Receiver Receiver
- DeviceNet No
- Input/Output Discrete
- Special Feature: Intrinsically Safe No
- Lens Material Acrylic
- Feature: Chemical Resistant No
- Connection Integral QD
- Special Feature: Remote Teach No
- Adjustments Potentiometer
- Feature: Timing (Hold/Delay) No
- Feature: Hazardous Area No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of Q45XB6RQ on Powermatic Associates is $140.00. Order now.
About the product
Banner Engineering Q45XB6RQ is a photo-electric sensor designed for through-beam system applications with an opposed mode potentiometer adjustment. It features a rectangular shape with a thermoplastic housing and an acrylic lens. This sensor operates within an ambient air temperature range of -40 to +70°C and offers a sensing distance of up to 60 meters. It is equipped with a 5-pin 7/8" mini connector for connectivity and operates on a supply voltage of 10Vdc to 30Vdc, with nominal voltages of 12Vdc and 24Vdc. The Q45XB6RQ, part of the Q45X series, provides a degree of protection rated at IP67 NEMA 6P, making it suitable for various industrial environments. It utilizes infrared light with a wavelength of 880 nm and supports both Light-ON and Dark-ON operating modes. The sensor includes 1 x digital output (PNP/NPN transistor) and boasts a quick response time of 2ms / 0.002 s.
