PVA100N6EQ Banner Optical Sensors

Name: PVA100N6EQ
Brand: Banner
Price: 321 USD
Availability: BackOrder

Banner PVA100N6EQ PVA Series: 100 mm Array - Emitter; Range: 2 m; Input: 12-30 V dc; Output: Not Applicable; M12 Integral QD

Part#:PVA100N6EQ

Manufacturer:Banner

Alt. Part#:51929

Product Lifecycle:Active

Get a quick Quote!

PVA Series: 100 mm Array - Emitter; Range: 2 m; Input: 12-30 V dc; Output: Not Applicable; M12 Integral QD

About the manufacturer: Banner is one of the manufacturers that offers Optical Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the PVA100N6EQ Banner price in the box on the right side or send a quick quote.

Product Details

Weight
217.72416 g
Country Of Origin
MX
Job Light
Green
Pro-Editor Compatible (Discrete)
No
Wireless
No
Modbus RTU
No
IO Link
No
Feature: Chemical Resistant
No
Sensing Resolution (mm)
35.0
Feature: Audible
No
Feature: Hazardous Area
No
Primary Window Material
Acrylic Clear
Button Operation
Momentary
Primary Housing Color
Black
Max Op. Temperature (°C)
50
NEMA Type and UL Type Rating
NEMA 2
Number of Beams
5
Environmental Rating
IP62
Physical Dimensions (LxWxH or DxH mm)
137.8 x 30.0 x 15.0
Beam Spacing (mm)
25.0

Array Length (mm)

100.0

Sensing Array Length (mm)

100

Maximum Sensing Distance (mm)

2000

Max Output Response Time (ms)

Input Type

Bimodal (PNP/NPN)

Supply Voltage

12-30 V dc

Number of Input Pins/Conductors

Max Current Color (mA)

Quick Disconnect Type

M12 (Euro)

Connection

Pigtail QD

Color Option 1

Green

Product Size (mm)

Other

Color Input Control

Individual (One wire/color, same number of colors as input wires)

Activation Function

Optical

Mounting Thread

No Thread

Number of Colors / Segments

Animation Option 1

Dip-Switch Controlled

Color Technology

Standard LED

Primary Housing Material

Aluminum

Housing Style

Flat Mount - Array

Sensing Mode (General)

Opposed

Sensing Mode (Detailed)

Emitter

Power

Power Source

Cable Length (m)

0.5

Actuation

Yes

Product series / family name

PVA

Digital outputs

4 x digital outputs (12-30Vdc; NPN)

Material

Acrylic Clear (window) Aluminum (housing)

Technology used in component

LED

Light Color

Green

Length (mm)

(array) 100 mm

Primary brand

Banner Engineering

Functions

Flat-mount array optical sensor for error-proofing of bin handpicking operations - through-beam sensing emitter only

Frame color

Black

Compliant with standard(s)

CE cULus Listed

Sensing distance

2m / 2000 mm

Connection type

Pre-wired (pigtail) 4-pin M12 connector

Visual position indicator

green LED (power ON) red LED (frequency selected)

Current consumption

62mA / 0.062 A

Supply voltage (DC)

12-30Vdc (12Vdc-24Vdc nom.)

Main function

Sensor (Array)

Mounting mode

Surface Pole

Degree of protection

IP62 NEMA 2

Ambient air temperature for operation

0...+50 °C

Order code / Manufacturer SKU

51929

Net Height (mm)

(sensing height) 6.5" / 100 mm

Maximum temperature

50 °C

Supply voltage

(DC) 12-30 V

Length (m)

(cable) 2 m

Distance

(beam spacing) 25mm

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

PVA100N6EQ Description

Banner Engineering PVA100N6EQ is a photo-electric array sensor designed for industrial applications, featuring a receiver alone configuration. It operates within an ambient air temperature of up to +50°C and has a net height of 15 mm. This sensor is pre-wired with a 2m cable that terminates with bare end flying leads, ensuring easy integration into existing systems. The device spans 100mm in array length and is protected by an IP62 NEMA 2 rated aluminium housing with an acrylic window, making it suitable for various environments. It requires a supply voltage of 12Vdc to 30Vdc, with 24Vdc being nominal. The PVA100N6EQ has a rectangular shape, measures 30 mm in width and 138 mm in depth, and offers a sensing distance of up to 2m with a 25mm beam spacing/pitch. It emits green light for detection purposes. The operating modes include NO (Normally Open) and NC (Normally Closed), and it features 1 x digital output (NPN transistor) with a current consumption of 62mA / 0.062 A.

$321.00

Request a quote, and we will send availability within minutes.

Select Qty:

$321.00

$321.00 each

Average response time: 11 minutes
