M18TUP14 Banner Temperature Sensors

M18TUP14 on Powermatic Associates
Banner

Part#:M18TUP14

Manufacturer:Banner

Alt. Part#:74921

Product Lifecycle:Active

Get a quick Quote!

M18T Series: Temperature Sensor; 14: 1 Germanium Lens; Output: Analog 0-10 V; PNP Alarm; 2 m (6.5 ft) Cable

About the manufacturer: Banner is one of the manufacturers that offers Temperature Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the M18TUP14 Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    136.0776 g
  • Country Of Origin
    US
  • 1-wire Serial Interface
    Yes
  • Wireless
    No
  • SSI
    No
  • IO Link
    No
  • Feature: Health/ Marginal Signal Output
    Yes
  • RS-422
    No
  • Profibus
    No
  • PROFINET
    No
  • RS-232
    No
  • RS-485
    No
  • Common Ethernet Protocol
    No
  • Feature: Timing (Hold/Delay)
    No
  • Feature: Quick Disconnect
    Yes
  • Minimum Window Size (mm)
    3 °C
  • Barrel Diameter (mm)
    18
  • Feature: Pump-in/ Pump-out
    No
  • Feature: Chemical Resistant
    Yes
  • Warm-up Time (minutes)
    5
  • Minimum Response Time (ms)
    25
  • Analog Linearity (mm)
    From 0 °C to +50 °C: ± 2 °C From +50 °C to +300 °C: ±1 °C or ±1%, whichever is greater
  • Feature: Remote Teach
    Yes
  • Remote Teach and Laser Control Input Impedence
    3 kΩ
  • Window Material
    Germanium
  • Min Operating Temperature (°C)
    -20
  • NEMA Rating
    NEMA 6
  • Max Operating Temperature (°C)
    70
  • Storage Temperature (°C)
    -25 to 75
  • Delay at Power-up (ms)
    1500
  • Adjustments
    Push Button; Remote Teach
  • Power Supply
    12-30 V dc
  • IP Rating
    IP67
  • Analog Resolution/Discrete Repeatability
    ± 1% of measurement, or ± 1 °C, whichever is greater
  • Quick Disconnect Type
    No QD
  • Analog Voltage Output Rating
    2.5 kΩ minimum load resistance
  • Number of Pins
    5
  • Analog Output Configuration
    0-10 V
  • Connection
    Flying Leads
  • Indicator
    LED(s)
  • Input/Output
    Analog
  • Sensing Beam
    N/A
  • PC Configurable
    Yes
  • Primary Housing Material
    Stainless Steel
  • Housing Style
    Barrel
  • Device Type
    Sensor
  • Sensing Mode (Detailed)
    Diffuse
  • Sensing Mode (General)
    Proximity
  • Cable Length (m)
    2
  • Power
    DC
  • Main function
    Sensor (Temperature)
  • Light Color
    Infrared (IR)
  • Product series / family name
    T-GAGE series
  • Temperature
    0...+300°C measurement range
  • Digital outputs
    1 x digital output (PNP transistor) (alarm)
  • Order code / Manufacturer SKU
    74921
  • Supply voltage (DC)
    12Vdc-30Vdc (24Vdc nom.)
  • Shape
    Cylindrical threaded/barrel
  • Degree of protection
    IP67 NEMA 6
  • Primary brand
    Banner Engineering
  • Functions
    Non-contact Infrared (IR) temperature sensor/transmitter green LED (power ON) amber LED (output state) red LED (teach active) TEACH mode
  • Thread size
    M18
  • Material
    stainless steel (304) housing ABS / polycarbonate p.button housing santoprene (p. button) Germanium lens Acrylic lightpipes
  • Sub-range name
    M18T series
  • Design
    Germanium lns. analog voltage output
  • Connection type
    Pre-wired with 6.5ft / 2m cable terminated with bare end flying leads
  • Analog outputs
    1 x analog output (0-10Vdc)
  • Compliant with standard(s)
    cURus CE
  • Response time
    75ms / 0.075 s
  • Ambient air temperature for operation
    -20...+70 °C

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

M18TUP14 Description

Banner Engineering M18TUP14 is a non-contact Infrared (IR) temperature sensor/transmitter belonging to the M18T series. It features a design incorporating Germanium lens and TEACH mode for precise operation. The sensor is housed in stainless steel 304 with an ABS / Polycarbonate (PC) push button housing, Thermoplastic vulcanizate (TPV) push button, and acrylic light pipes, ensuring durability and resilience. It comes pre-wired with a 6.5ft / 2m cable terminated with bare end flying leads for easy installation. The M18TUP14 operates on a supply voltage of 12Vdc-30Vdc, with 24Vdc nominal, and can measure temperatures ranging from 0 to +300°C. It is designed to function within an ambient air temperature range of -20 to +70°C. This sensor offers a high degree of protection with an IP67 NEMA 6 rating, making it suitable for challenging environments. It provides one analog output (0-10Vdc) and one digital output (PNP transistor) for alarm signaling, with a response time of 75ms / 0.075 s. The sensor's M18 cylindrical threaded/barrel shape facilitates straightforward mounting.
