M18TB6E Banner Temperature Sensors

Name: M18TB6E
Brand: Banner
Price: 397 USD
Availability: BackOrder

Part#:M18TB6E

Manufacturer:Banner

Alt. Part#:73648

Product Lifecycle:Active

Get a quick Quote!

M18T Series: Temperature Sensor; 6: 1 Plastic Fresnel Lens; Output: one NPN, one PNP; 2 m Cable

About the manufacturer: Banner is one of the manufacturers that offers Temperature Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the M18TB6E Banner price in the box on the right side or send a quick quote.

Product Details

Weight
20.865232 g
Country Of Origin
US
Profibus
No
RS-485
No
1-wire Serial Interface
Yes
Wireless
No
SSI
No
RS-232
No
PROFINET
No
RS-422
No
Common Ethernet Protocol
No
IO Link
No
Feature: Chemical Resistant
Yes
Feature: Timing (Hold/Delay)
No
Feature: Remote Teach
Yes
Feature: Quick Disconnect
Yes
Feature: Pump-in/ Pump-out
No
Storage Temperature (°C)
-25 to 75
Minimum Window Size (mm)
3 °C
Remote Teach and Laser Control Input Impedence
3 kΩ

Max Operating Temperature (°C)

Barrel Diameter (mm)

Minimum Response Time (ms)

Min Operating Temperature (°C)

-20

Warm-up Time (minutes)

Adjustments

Push Button; Remote Teach

NEMA Rating

NEMA 6

Discrete (Switched) Outputs

Bipolar (NPN & PNP)

Number of Pins

IP Rating

IP67

Delay at Power-up (ms)

1500

Analog Resolution/Discrete Repeatability

1 °C

Quick Disconnect Type

No QD

Indicator

LED(s)

Connection

Flying Leads

Input/Output

Discrete

Primary Housing Material

Stainless Steel

Power Supply

12-30 V dc

Sensing Mode (Detailed)

Diffuse

PC Configurable

Yes

Sensing Beam

N/A

Device Type

Sensor

Housing Style

Barrel

Cable Length (m)

Power

Sensing Mode (General)

Proximity

Sub-range name

M18T series

Digital outputs

1 x digital output (PNP transistor) 1 x digital output (NPN transistor)

Product series / family name

T-GAGE series

Supply voltage (DC)

12Vdc-30Vdc (24Vdc nom.)

Response time

25ms / 0.025 s

Order code / Manufacturer SKU

73648

Main function

Sensor (Temperature)

Temperature

0...+300°C measurement range

Shape

Cylindrical threaded/barrel

Compliant with standard(s)

cURus CE

Primary brand

Banner Engineering

Design

enclosed plastic optical lns.

Connection type

Pre-wired with 6.5ft / 2m cable terminated with bare end flying leads

Degree of protection

IP67 NEMA 6

Functions

Non-contact Infrared (IR) temperature switch/sensor green LED (power ON) amber LED (output state) red LED (teach active) TEACH mode

Thread size

M18

Ambient air temperature for operation

-20...+70 °C

Material

stainless steel (304) housing ABS / polycarbonate p.button housing santoprene (p. button) Enclosed plastic lens Acrylic lightpipes

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

M18TB6E Description

Banner Engineering M18TB6E is a non-contact infrared (IR) temperature switch/sensor, part of the M18T series, designed for temperature measurement. It features an enclosed plastic optical lens and operates with a TEACH mode for easy setup. The sensor has an M18 cylindrical threaded/barrel shape with a housing made of Stainless steel 304, an ABS / Polycarbonate (PC) push button housing, Thermoplastic vulcanizate (TPV) push button, and Acrylic light pipes. It comes pre-wired with a 6.5ft / 2m cable terminated with bare end flying leads for connection. The supply voltage required is 12Vdc-30Vdc, with 24Vdc nominal. It can measure temperatures ranging from 0 to +300°C and is suitable for ambient air temperatures from -20 to +70°C. The sensor offers a degree of protection of IP67 NEMA 6, ensuring durability in various environments. It features a thread size of M18 and includes 1 x digital output (PNP transistor) and 1 x digital output (NPN transistor) for versatile connectivity. The response time of the sensor is 25ms / 0.025 s.
