M12FTH3Q Banner Electronic Components

Name: M12FTH3Q
Brand: Banner
Price: 299 USD
Availability: InStock

Banner M12FTH3Q Banner Engineering M12FTH3Q is a sensor designed for measuring ambient temperature and humidity, belonging to the M12F series. This sensor features a metal housing in an M12 cylindrical threaded/barrel shape, ensuring durability and ease of installation. It is pre-equipped with a 5-pin Euro-style M12 connector for straightforward connectivity. The M12FTH3Q operates using the Modbus RTU RS-485 communication protocol, allowing for efficient data transmission. It requires a supply voltage ranging from 12Vdc to 24Vdc and can measure temperatures within a range of -40 to +85°C. For output, it offers 1 x digital output (NMOS output; low-active). The sensor is designed to withstand harsh environments, evidenced by its IP67 NEMA 6 rating for protection against dust and water ingress. The thread size for mounting is M12, facilitating its integration into various applications.

Part#:M12FTH3Q

Manufacturer:Banner

Product Lifecycle:Active

In-stock parts: 1

Sep 28, 2024

Banner Engineering M12FTH3Q is a sensor designed for measuring ambient temperature and humidity, belonging to the M12F series. This sensor features a metal housing in an M12 cylindrical threaded/barrel shape, ensuring durability and ease of installation. It is pre-equipped with a 5-pin Euro-style M12 connector for straightforward connectivity. The M12FTH3Q operates using the Modbus RTU RS-485 communication protocol, allowing for efficient data transmission. It requires a supply voltage ranging from 12Vdc to 24Vdc and can measure temperatures within a range of -40 to +85°C. For output, it offers 1 x digital output (NMOS output; low-active). The sensor is designed to withstand harsh environments, evidenced by its IP67 NEMA 6 rating for protection against dust and water ingress. The thread size for mounting is M12, facilitating its integration into various applications.

About the manufacturer: Banner is one of the manufacturers that offers Electronic Components that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the M12FTH3Q Banner price in the box on the right side or send a quick quote.

Product Details

1-wire Serial Interface
No
RS-232
No
Wireless
No
RS-485
Yes
PROFINET
No
Modbus/TCP
No
Modbus RTU
Yes
EtherNet/IP
No
Application: Relative Humidity Input
Yes
Application: Temperature Input
Yes
Feature: Hazardous Area
Yes
Relative Humidity
100%
Min Temp Operating Conditions
-40
Max Operating Temperature ( °C)
85
Min Operating Temperature ( °C)
-40
Hazardous/Intrinsically Safe Classification
Class I, Division 2
Input/Output
Serial (Modbus)
Max Temp Operating Conditions
85
Environmental Rating (NEMA)
NEMA 6
Environmental Rating (IP)
IP67

Input Details

Temperature/Humidity

Power Supply

12-24 V dc or 3.6-5.5 V dc low power option

Device Type

Sensor

Housing Style

Barrel - Straight

Power

Primary brand

Banner Engineering

Sub-range name

M12F

Shape

Cylindrical threaded/barrel

Compliant with standard(s)

cCSAus

Main function

Sensor (Temperature)

Functions

Ambient temperature/humidity sensor green LED (power ON) red LED (output state)

Thread size

M12

Material

metal housing

Order code / Manufacturer SKU

25898

Communication protocol

Modbus RTU RS-485

Product series / family name

SureCross series

Degree of protection

IP67 NEMA 6

Supply voltage (DC)

12Vdc-24Vdc

Connection type

Pre-equipped with 5-pin Euro-style M12 connector

Ambient air temperature for operation

-40...+85 °C

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

$299.00

Stock:

Select Qty:

$299.00

$299.00 each

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
