M18TB14 Banner Temperature Sensors

M18TB14 on Powermatic Associates
Banner
  • M18TB14
  • M18TB14

Part#:M18TB14

Alt. Part#:73651

Manufacturer:Banner

Category:Temperature Sensors

Product Lifecycle:Active

Product description

M18T Series: Temperature Sensor; 14: 1 Germanium Lens; Output: one NPN, one PNP; 2 m Cable

Product Details

  • Weight
    208.65232 g
  • Country Of Origin
    US
  • Profibus
    No
  • Wireless
    No
  • RS-485
    No
  • 1-wire Serial Interface
    Yes
  • RS-232
    No
  • Feature: Pump-in/ Pump-out
    No
  • Min Operating Temperature (°C)
    -20
  • Discrete (Switched) Outputs
    Bipolar (NPN & PNP)
  • Power
    DC
  • SSI
    No
  • RS-422
    No
  • PROFINET
    No
  • Common Ethernet Protocol
    No
  • Feature: Timing (Hold/Delay)
    No
  • Feature: Remote Teach
    Yes
  • Feature: Chemical Resistant
    Yes
  • Barrel Diameter (mm)
    18
  • IO Link
    No
  • Feature: Quick Disconnect
    Yes
  • Remote Teach and Laser Control Input Impedence
    3 kΩ
  • Minimum Window Size (mm)
    3 °C
  • Window Material
    Germanium
  • Storage Temperature (°C)
    -25 to 75
  • Max Operating Temperature (°C)
    70
  • NEMA Rating
    NEMA 6
  • Minimum Response Time (ms)
    25
  • Delay at Power-up (ms)
    1500
  • IP Rating
    IP67
  • Number of Pins
    5
  • Warm-up Time (minutes)
    5
  • Quick Disconnect Type
    No QD
  • Adjustments
    Push Button; Remote Teach
  • Power Supply
    12-30 V dc
  • Analog Resolution/Discrete Repeatability
    1 °C
  • Connection
    Flying Leads
  • Input/Output
    Discrete
  • Indicator
    LED(s)
  • PC Configurable
    Yes
  • Sensing Mode (General)
    Proximity
  • Housing Style
    Barrel
  • Primary Housing Material
    Stainless Steel
  • Sensing Mode (Detailed)
    Diffuse
  • Device Type
    Sensor
  • Cable Length (m)
    2
  • Sensing Beam
    N/A
  • Functions
    Non-contact Infrared (IR) temperature switch/sensor green LED (power ON) amber LED (output state) red LED (teach active) TEACH mode
  • Shape
    Cylindrical threaded/barrel
  • Order code / Manufacturer SKU
    73651
  • Sub-range name
    M18T series
  • Thread size
    M18
  • Digital outputs
    1 x digital output (PNP transistor) 1 x digital output (NPN transistor)
  • Material
    stainless steel (304) housing ABS / polycarbonate p.button housing santoprene (p. button) Germanium lens Acrylic lightpipes
  • Main function
    Sensor (Temperature)
  • Design
    Germanium lns.
  • Response time
    25ms / 0.025 s
  • Ambient air temperature for operation
    -20...+70 °C
  • Primary brand
    Banner Engineering
  • Temperature
    0...+300°C measurement range
  • Connection type
    Pre-wired with 6.5ft / 2m cable terminated with bare end flying leads
  • Compliant with standard(s)
    cURus CE
  • Product series / family name
    T-GAGE series
  • Supply voltage (DC)
    12Vdc-30Vdc (24Vdc nom.)
  • Degree of protection
    IP67 NEMA 6

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of M18TB14 on Powermatic Associates is $413.00. Order now.


About the product

Banner Engineering M18TB14 is a non-contact infrared (IR) temperature switch/sensor belonging to the M18T series. It features a design incorporating a Germanium lens and TEACH mode for precise operation. The sensor has an M18 cylindrical threaded/barrel shape with a housing made of stainless steel 304, an ABS / Polycarbonate (PC) push button housing, Thermoplastic vulcanizate (TPV) for the push button, a Germanium lens, and Acrylic light pipes. It comes pre-wired with a 6.5ft / 2m cable terminated with bare end flying leads for connectivity. The M18TB14 operates on a supply voltage of 12Vdc-30Vdc, with 24Vdc nominal, and can measure temperatures ranging from 0 to +300°C. It is designed to function in ambient air temperatures from -20 to +70°C. This sensor offers a high degree of protection with an IP67 NEMA 6 rating, ensuring its durability in various environments. It features an M18 thread size and provides digital outputs through 1 x PNP transistor and 1 x NPN transistor, with a response time of 25ms / 0.025 s for rapid temperature detection.
