M18TIP6EQ Banner Temperature Sensors

Product Details

• Weight
  113.398 g
• Country Of Origin
  US
• Wireless
  No
• RS-422
  No
• 1-wire Serial Interface
  Yes
• SSI
  No
• RS-485
  No
• Common Ethernet Protocol
  No
• IO Link
  No
• Feature: Pump-in/ Pump-out
  No
• Remote Teach and Laser Control Input Impedence
  3 kΩ
• Feature: Timing (Hold/Delay)
  No
• Feature: Remote Teach
  Yes
• Barrel Diameter (mm)
  18
• Minimum Response Time (ms)
  25
• IP Rating
  IP67
• Storage Temperature (°C)
  -25 to 75
• NEMA Rating
  NEMA 6
• Analog Linearity (mm)
  From 0 °C to +50 °C: ± 2 °C From +50 °C to +300 °C: ±1 °C or ±1%, whichever is greater
• Number of Pins
  5
Indicator
LED(s)
Connection
Integral QD
Quick Disconnect Type
M12 (Euro)
Power Supply
12-30 V dc
Delay at Power-up (ms)
1500
Analog Output Configuration
4-20 mA
Sensing Mode (Detailed)
Diffuse
PC Configurable
Yes
Housing Style
Barrel
Sensing Mode (General)
Proximity
Primary Housing Material
Stainless Steel
Profibus
No
RS-232
No
PROFINET
No
Feature: Health/ Marginal Signal Output
Yes
Minimum Window Size (mm)
3 °C
Feature: Chemical Resistant
Yes
Feature: Quick Disconnect
Yes
Warm-up Time (minutes)
5
Min Operating Temperature (°C)
-20
Max Operating Temperature (°C)
70
Analog Current Output Rating
1 kΩ max @24 V dc, max load resistance = [(Vcc-4 V)/0.02 A] Ω
Adjustments
Push Button; Remote Teach
Analog Resolution/Discrete Repeatability
± 1% of measurement, or ± 1 °C, whichever is greater
Input/Output
Analog
Device Type
Sensor
Power
DC
Sensing Beam
N/A
