Industrial Automation Components - HMS Networks

Ewon by HMS Networks E-022 is an antenna designed for 2G/3G/4G cellular applications, featuring a magnetic foot for external mounting. It operates across transmission frequencies of 850 MHz, 900 MHz, 1800 MHz, 1900 MHz, and 2100 MHz. This model, part of the Accessories sub-range, is equipped with a 2.2dBi gain cable and utilizes a 1 x SMA male connector for connectivity. The antenna includes a 5m cable to facilitate flexible installation options.

Industrial Internet Router w/antenna (Ethernet + WiFi 802.11 b/g/n)

Cosy 131 Cellular (GSM) 4G

Anybus by HMS Networks AB7956-F is a gateway within the X-gateway series designed for protocol translation. It features a CC-Link IE Field slave and EtherNet/IP adapter configuration, supporting installation in both vertical and flat orientations with galvanic isolation on both BUS and Ethernet sides. Configuration is managed via a USB port using the Anybus Configuration Manager software. The device includes 8 configuration switches, 8 IP configuration switches, and 10 LED indicators for fieldbus, sub-network, and device status monitoring. It operates on a supply voltage of 19.2-28.8Vdc (24Vdc nominal) and has dimensions of H127mm x W44mm x D114mm. The housing is made from aluminium and plastic, ensuring durability. Connection options include 2 x RJ45 CC-Link IE Field connectors, 2 x RJ45 LAN connectors for 10/100Mbit/s Ethernet/IP (supporting both full and half duplex), 1 x 2-poles 5.08mm plug-in screw connector for power, and 1 x USB connector for configuration. It offers an IP20 and NEMA 1 degree of protection and is designed for DIN rail mounting. The AB7956-F supports CC-Link and Ethernet/IP communication protocols, operates within an ambient air temperature range of -25 to +65°C, and consumes a maximum of 400mA (24Vdc) or typically 200mA. It is designed for storage in temperatures ranging from -40 to +85°C and can operate in environments with 5-95% relative humidity (non-condensing). The gateway facilitates speeds of 1Gbit/s for CC-Link IE Field and 10/100Mbit/s for Ethernet, catering to a variety of industrial automation needs.

Industrial Internet router - eWON Flexy2

Anybus by HMS Networks AB7841-F is a gateway designed for protocol translation within the X-gateway series. It functions as a CC-Link slave and EtherNet/IP adapter, facilitating communication between different industrial networks. The device supports vertical or flat installation and features galvanic isolation on both BUS and Ethernet sides to prevent electrical interference. Configuration is managed via a USB port using the Anybus Configuration Manager software. The AB7841-F is equipped with 8 IP configuration switches, 2 station address switches for easy network addressing, and a baud rate switch to adjust communication speed. It also includes 10 LED indicators for monitoring fieldbus, sub-network, and device status. The gateway operates on a supply voltage of 19.2-28.8Vdc, with a nominal 24Vdc, and has dimensions of H127mm x W44mm x D114mm. Its housing is made from aluminium and plastic, ensuring durability while maintaining a lightweight design. For connectivity, it offers 2 RJ45 LAN connectors for 10/100Mbit/s Ethernet/IP communication in both full and half duplex modes, a 5-pin CC-Link connector, a 2-poles 5.08mm plug-in screw connector for power, and a USB connector for configuration. The AB7841-F is designed for DIN rail mounting and has an IP20 and NEMA 1 degree of protection, making it suitable for use in controlled environments. It supports CC-Link and Ethernet/IP communication protocols, operates within an ambient air temperature range of -25 to +65 °C, and consumes a maximum of 400mA at 24Vdc. For storage, it can withstand temperatures from -40 to +85 °C. The device's Ethernet speed is 10/100Mbit/s, and it supports CC-Link speeds from 156kbit/s to 10Mbit/s. It is designed to operate in environments with 5-95% relative humidity, non-condensing.

HMS eWon component

HMS eWon component

Anybus by HMS Networks AB7630-F is a gateway belonging to the X-gateway series designed to function as a protocol translator gateway. It supports installation in both vertical and flat positions and features galvanic isolation on both BUS/Ethernet sides. The I/O configuration is manageable via a USB port using the Anybus Configuration Manager software. This device combines a DeviceNet scanner and a Modbus TCP server, equipped with 8 configuration switches, 8 IP configuration switches, and 10 LED indicators for fieldbus, sub-network, and device status monitoring. It operates on a supply voltage of 19.2-28.8Vdc, with 24Vdc nominal. The dimensions are H127mm x W44mm x D114mm, and it is constructed from aluminium and plastic housing. Connection interfaces include 2 x RJ45 connectors for 10/100Mbit/s Modbus TCP (supporting both full and half duplex), 1 x 5-pin plug-in connector for DeviceNet, 1 x 2-poles 5.08mm plug-in screw connector for power, and 1 x USB connector for configuration. It offers an IP20 and NEMA 1 degree of protection and is designed for DIN rail mounting. The communication protocols supported are DeviceNet and Modbus TCP. It is operational within an ambient air temperature range of -25 to +65 °C, with a current consumption of 400mA (max) and 200mA (typical) at 24Vdc. The device can be stored in temperatures ranging from -40 to +85 °C and operates efficiently in environments with 5-95% relative humidity (non-condensing). The supported speeds are 10/100Mbit/s for Modbus TCP and 125kbit/s, 250kbit/s, or 500kbit/s for DeviceNet.

Anybus by HMS Networks AWB2031-B is a Wireless LAN (WLAN) unit within the Wireless Bolt Ethernet PoE series designed to facilitate wireless configuration and troubleshooting of machinery. This unit allows for machine access within a 100-meter range via a laptop, tablet, or smartphone without the need for physical presence or an expensive HMI, supporting BYOD practices. It integrates a connector, communication processor, and antenna in a single unit with IP67 exterior protection. The WLAN interface supports 802.11 a/b/g/n/d standards, operates in Access Point or Client modes, covers 2.4GHz and 5GHz bands, and offers a maximum link speed of 65Mbps with a net data throughput of 20Mbps. It can connect to up to 7 slaves as an access point and ensures security through various protocols including WEP, WPA, and WPA2. The Bluetooth interface supports Classic Bluetooth v2.1 with a net data throughput of around 1Mbps and the Bluetooth Low Energy interface supports version 4.0 dual-mode with a net data throughput of around 200kbps. The Ethernet interface is compatible with various protocols including IP, TCP, and UDP, and supports wireless bridging of Industrial Ethernet protocols like BACnet/IP and PROFINET. The unit features a white top and black base, requires a supply voltage of 19-36Vdc, and has dimensions of 84mm in height with a 68mm diameter. It is housed in a plastic casing made of PBT/PC, connects via an RJ45 connector or a 3-poles plug-in screw connector for power, and is designed for M50 screw/nut mounting. The AWB2031-B operates within an ambient air temperature range of -40 to +65 °C and has a maximum power consumption of 1.7W when idle.
