Anybus by HMS Networks AB7658-F is a gateway designed for protocol translation within the X-gateway series. It functions as a CANopen slave and PROFINET-IO device, featuring vertical or flat installation positions with galvanic isolation on both BUS and Ethernet sides. Configuration is managed via a USB port using Anybus Configuration Manager software. The device includes 2 node address switches (x10 / x1), 1 baud rate switch, and 10 LED indicators for fieldbus, sub-network, and device status. It operates on a supply voltage of 19.2-28.8Vdc (24Vdc nom.) and has dimensions of H127mm x W44mm x D114mm. The housing is made from aluminium and plastic, with connections including 1 x RJ45 LAN connector for 100Mbit/s Ethernet (PROFINET I.O.; full duplex), 1 x 9-pin D-sub male connector for CANopen, 1 x 2-poles 5.08mm plug-in screw connector for power (X3), and 1 x USB connector (X4). It offers an IP20 NEMA 1 degree of protection and is designed for DIN rail mounting. The communication protocols supported are CANopen and PROFINET IO, with an ambient air temperature for operation ranging from -25 to +65°C. Current consumption is 400mA (max.) and 200mA (typical) at 24Vdc, with an ambient air temperature for storage between -40 and +85°C. The speed supported is 100Mbit/s for PROFINET and 10kbit/s to 1Mbit/s for CANopen slave, in environments with 5-95% relative humidity (non-condensing).

Anybus by HMS Networks AB7806-F is a gateway belonging to the X-gateway series designed for protocol translation. It functions as a PROFIBUS master and Interbus Fiber Optic slave, facilitating communication between these two distinct networks. The gateway is equipped with 10 LED indicators for monitoring fieldbus, sub-network, and device status, and features a baud rate jumper for speed adjustments. It supports a supply voltage range of 19.2-28.8Vdc, with a nominal voltage of 24Vdc. The AB7806-F has dimensions of H127mm x W44mm x D114mm and is constructed from aluminium and plastic, ensuring durability while maintaining a lightweight design. Connection options include 2 fiber optic RX and TX connectors for bus-in and bus-out, a 9-pin D-sub female connector for PROFIBUS X1.1, a 9-pin D-sub male connector for PROFIBUS X1.2 and RS-232 configuration, a 2-poles 5.08mm plug-in screw connector for power, and a USB connector for I/O configuration via Anybus Configuration Manager software. It offers an IP20 and NEMA 1 degree of protection and is designed for DIN rail mounting. The AB7806-F operates within an ambient air temperature range of -25 to +65 °C and can be stored in temperatures ranging from -40 to +85 °C. It consumes a maximum of 400mA at 24Vdc and typically 200mA. The gateway supports communication speeds up to 12Mbit/s for PROFIBUS and between 500kbit/s to 2Mbit/s for INTERBUS, and is designed to operate in environments with 5-95% relative humidity, non-condensing.

Anybus by HMS Networks AB7898-F is a gateway designed for protocol translation within the X-gateway series. It functions as both a CANopen slave and a LonWorks slave, featuring vertical or flat installation positions with galvanic isolation on both BUS/Ethernet sides. Configuration of I/O is managed via a USB port using the Anybus Configuration Manager software. This part includes 1 service pin, 2 node address switches (x10 / x1), 1 baud rate switch, and 10 LED indicators for fieldbus, sub-network, and device status monitoring. It operates on a supply voltage of 19.2-28.8Vdc (24Vdc nominal) and has dimensions of H127mm x W44mm x D114mm. The housing is made from aluminium and plastic, ensuring durability and resilience. Connection options include 1 x 9-pin D-sub male connector for serial RS-232 configuration, 1 x 5-pin plug-in connector for LonWorks, 1 x 9-pin D-sub male connector for CANopen, 1 x 2-poles 5.08mm plug-in screw connector for power (X3), and 1 x USB connector (X4) for software configuration. It offers an IP20 NEMA 1 degree of protection and is designed for DIN rail mounting. The AB7898-F supports communication protocols CANopen and LONworks, operates within an ambient air temperature range of -25 to +65 °C for operation and -40 to +85 °C for storage. It has a current consumption of 400mA (max) and 200mA (typical) at 24Vdc, with a speed range of 10kbit/s to 1Mbit/s for CANopen slave and 78kbit/s for LonWorks. Humidity tolerance is specified at 5-95% relative humidity (RH; non-condensing).

Anybus by HMS Networks AB7970-F is a gateway belonging to the X-gateway series designed to function as a protocol translator between EtherCAT and PROFINET-IRT networks. It supports installation in both vertical and flat orientations and features galvanic isolation on both the BUS and Ethernet sides to enhance network integrity. Configuration of the I/O is facilitated via a USB port using the Anybus Configuration Manager software. This device integrates an EtherCAT slave and a PROFINET-IRT Fiber Optic device, equipped with 10 LED indicators for monitoring fieldbus, sub-network, and device status. It operates on a supply voltage range of 19.2-28.8Vdc, with a nominal voltage of 24Vdc, and has dimensions of H127mm x W44mm x D114mm. The housing is made from a combination of aluminium and plastic, ensuring durability while maintaining a lightweight design. Connection interfaces include 2 SC-RJ fiber optic network LAN connectors, 2 RJ45 connectors for 100Mbit/s full duplex EtherCAT communication, a 2-poles 5.08mm plug-in screw connector for power, and a USB connector for configuration. It offers a degree of protection rated at IP20 NEMA 1 and is designed for DIN rail mounting. The AB7970-F supports communication protocols EtherCAT and PROFINET, operates within an ambient air temperature range of -25 to +65 °C during operation and -40 to +85 °C for storage. It has a current consumption of 400mA at maximum and 200mA typically, with a communication speed of 100Mbit/s for both PROFINET and EtherCAT. The device is designed to operate in environments with 5-95% relative humidity, non-condensing.

Ixxat by HMS Networks 1.04.0076.00180 is a CAN cable/cordset designed for various automation applications. It features 3 x 9-pin D-sub male connectors and has a length of 2 meters (approximately 6 feet). The cable is rated for a voltage of 350Vdc with a testing voltage up to 800Vdc. It is designed with a shield and all pins are connected in a 1-to-1 configuration. The cable operates within an ambient air temperature range of 0 to +70 degrees Celsius. It supports the CAN communication protocol and falls under the Accessories sub-range.

HMS eWon component

Anybus by HMS Networks HMS-EN2MB-R is a gateway designed as part of the Linking Device Series, serving as a protocol translator between EtherNet/IP and Modbus TCP. It is intended for vertical installation and features galvanic isolation on both BUS and Ethernet sides. This device allows for the use of any valid IP address for both Modbus-TCP and EtherNet/IP, with TCP/IP settings configurable via BOOTP-DHCP server or Anybus IP config. It includes an SD Memory Card slot for easy module replacement, supported by 1 x SD card slot design. The HMS-EN2MB-R is equipped with 8 x LED indicators for status display and has dimensions of H110mm x W35mm x D101mm. Its housing is made from ABS / PC plastic, ensuring durability within its design specifications. Connection options include 2 x RJ45 connectors for 10/100Mbit/s Ethernet IP (full/half duplex), 2 x RJ45 connectors for 10/100Mbit/s Modbus TCP (full/half duplex), 1 x 3-poles plug-in screw connector for power, and 1 x USB connector. It supports Ethernet/IP and Modbus TCP communication protocols, operates on a supply voltage of 19.2-28.8Vdc (24Vdc nom.), and can be mounted on a DIN rail or wall. The device operates within an ambient air temperature range of -25...+70 °C, offers a degree of protection of IP20 NEMA 1, and has a current consumption of 300mA (24Vdc; max.) and 150mA (24Vdc; typical). Its speed is rated at 10/100Mbit/s for both Ethernet and Modbus connections, and it is designed for storage in ambient air temperatures ranging from -40...+85 °C.

Anybus by HMS Networks AB7880-F is a gateway within the X-gateway series designed for protocol translation. It functions as a FIPIO slave and LonWorks slave, featuring vertical or flat installation positions and galvanic isolation on both BUS/Ethernet sides. Configuration is managed via a USB port using Anybus Configuration Manager software. The device includes 1 x service pin, 2 x node address switches (x10 / x1), and 10 x LED indicators for fieldbus/sub-network/device status. It operates on a supply voltage of 19.2-28.8Vdc (24Vdc nom.) and has dimensions of H127mm x W44mm x D114mm. The housing is made of aluminium and plastic, with connection types including 1 x 9-pin D-sub male connector (FIPIO), 1 x 5-pin plug-in connector (LonWorks), 1 x 9-pin D-sub male connector (serial RS-232; configuration), 1 x 2-poles 5.08mm plug-in screw connector (power; X3), and 1 x USB connector (X4). It offers a degree of protection of IP20 NEMA 1 and is designed for DIN rail mounting. The communication protocols supported are FIPIO and LONworks, with an ambient air temperature for operation of -25...+65 °C and for storage of -40...+85 °C. The current consumption is 400mA (24Vdc; max.) and 200mA (typical), with a speed of 1Mbit/s (FIPIO) and 78kbit/s (LonWorks). It is designed to operate in environments with 5-95% relative humidity (RH; non-condensing).

Anybus by HMS Networks AB7889-F is a gateway belonging to the X-gateway series designed to function as a protocol translator. This part facilitates communication between CANopen and INTERBUS networks, featuring a CANopen slave and an Interbus Fiber Optic slave design. It supports vertical or flat installation positions and offers galvanic isolation on both BUS/Ethernet sides. The I/O configuration is manageable via a USB port using the Anybus Configuration Manager software. The AB7889-F includes 2 node address switches (x10 / x1), a baud rate switch, 10 LED indicators for fieldbus/sub-network/device status, and a baud rate jumper. It requires a supply voltage of 19.2-28.8Vdc (24Vdc nominal) and measures H127mm x W44mm x D114mm. The housing is made from aluminium and plastic, ensuring compatibility with various industrial environments. Connection options include 2 fiber optic TX connectors and 2 fiber optic RX connectors for bus-in/bus-out configurations, a 9-pin D-sub male connector for CANopen, a 2-poles 5.08mm plug-in screw connector for power, and a USB connector for configuration. It offers an IP20 NEMA 1 degree of protection and is designed for DIN rail mounting. The AB7889-F operates within an ambient air temperature range of -25 to +65 °C, with a current consumption of 400mA (max) and 200mA (typical). It supports storage temperatures from -40 to +85 °C and can operate in environments with 5-95% relative humidity (non-condensing). Communication speeds range from 500kbit/s to 2Mbit/s for INTERBUS and 10kbit/s to 1Mbit/s for the CANopen slave.

Anybus by HMS Networks AB7555-F is a gateway within the X-gateway IIoT series designed for IIoT applications. It supports vertical or flat installation and features galvanic isolation on both BUS/Ethernet sides. The I/O configuration is manageable via USB port using Anybus Configuration Manager software. This part is equipped with a Modbus TCP server and OPC UA-MQTT Ethernet dual-port cut-through switch, alongside 8 IP configuration switches and 10 LED indicators for various statuses. It operates on a supply voltage of 19.2-28.8Vdc (24Vdc nominal) and measures H127mm x W44mm x D114mm. The housing is made from aluminium and plastic, ensuring durability. Connection options include 2 RJ45 connectors for 10/100Mbit/s Ethernet (full/half duplex), 2 RJ45 connectors for 10/100Mbit/s Modbus TCP (full/half duplex), a 2-poles 5.08mm plug-in screw connector for power, and a USB connector for configuration. It offers an IP20 and NEMA 1 degree of protection and is designed for DIN rail mounting. The AB7555-F supports Modbus TCP and OPC UA communication protocols, operates within an ambient air temperature range of -25 to +65°C, and consumes a maximum of 400mA (24Vdc) or typically 200mA. It is designed for storage in temperatures ranging from -40 to +85°C and can operate in environments with 5-95% relative humidity (non-condensing). The connection speed is 10/100Mbit/s for both Ethernet and Modbus.
