714-135 WAGO Industrial Automation Components

714-135 on Powermatic Associates
WAGO

Part#:714-135

Manufacturer:WAGO

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

714-135 WAGO - THT male header; 0.8 x 0.8 mm solder pin; straight; Pin spacing 3.5 mm; 5-pole; black

Product Details

  • Weight
    1.1400003 g
  • Country Of Origin
    Germany
  • HTS Code
    85366990990
  • Voltage
    150 volts, 160 volts
  • Width
    0.744 inches, 18.9 millimeters
  • Weight
    1.140 grams
  • Package Type
    Box
  • Insulation Material
    Polyphthalamide
  • Height
    0.516 inches, 13.1 millimeters
  • Flammability Class
    V0
  • Current
    8 amperes, 8 amperes
  • Depth
    0.272 inches, 6.9 millimeters
  • Country of Origin
    Germany
  • Contact Type
    Tin
  • Contact Material
    Copper
  • Connection Type
    For PCB
  • Color
    Black

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 714-135 on Powermatic Associates is $2.07. Order now.


About the product

WAGO 714-135 is a male connector/plug designed for PCB applications, featuring a total of 5 potentials with a single connection type across one level. It has a nominal voltage rating of 160V (III/3), 160V (III/2), and 320V (II/2) with a rated impulse voltage of 2.5kV and a rated current of 8A according to IEC/EN standards. UL ratings include a rated voltage of 150V and a rated current of 8A for Use Group B. The connector has a pin spacing of 3.5mm, dimensions of 18.9mm in width, 13.1mm in height, 6.9mm in depth, and a solder pin length of 3.4mm. It features variable coding, anti-rotation protection, and is made from black Polyphthalamide (PPA GF) with tin-plated electrolytic copper contacts. It is designed for through-hole technology (THT) with a 90-degree mating direction to the PCB and does not support mismating protection or plugging without loss of pin spacing. The part is RoHS compliant, has a flammability class of UL94 V0, and operates within a temperature range of -60 to +100°C. It comes in a box packaging type with 200 pieces per unit, manufactured in Germany, and has a GTIN of 4045454858858.
