859-354
Wago 859-354 is a fixed-type relay module featuring CAGE-CLAMP spring connections for secure and maintenance-free connections. It is designed to handle a rated current of 5A continuously and can manage up to 20A AC inrush maximum current for 20ms. The module is equipped with a red LED and an electromechanical design, recommending a minimum switching load of 10V / 10mA / 24V / 1mA. It includes a 1C/O / SPDT (Single Pole Double Throw) contact type and operates within an ambient air temperature range of -40°C to +50°C for operation and -40°C to +70°C for storage. The control voltage ranges from 20.4-26.4Vdc (24Vdc nominal) and 20.4-26.4Vac (24Vac nominal) for DC and AC respectively, with a power consumption of 0.85...1.1 x Uc. Its design allows for a net height of H91mm x W6mm x D56mm, fitting a 6mm width on a DIN-35 rail. The relay module's contacts are made of Silver-Tin (AgSnO), ensuring durability and a reliable connection. It has a rated impulse voltage (Uimp) of 0.85...1.1 x Uc, a net width of 250Vac max. (switching voltage), and a rated insulation voltage (Ui) of 4 kV. The rated operating voltage (Ue) and the speed of contacts closing and opening are specified as 15ms / 0.015 s and 25ms / 0.025 s, respectively. It is designed for a distance of 250 V and a rated voltage (AC) - Phase-to-phase of 50 000 operations, with a power dissipation/losses of 5 000 000 operations. The module is recommended for environments with 5-95% relative humidity (RH), with no condensation permissible.
WAGOSTOCK: 0
