2092-1102 WAGO Industrial Automation Components

WAGO 2092-1102 is a picoMAX Pluggable Connection System connector designed for use in applications as specified by DIN EN 61984, featuring connectors without breaking capacity. It operates with a nominal voltage of 250V (III/3), 320V (III/2), and 630V (II/2), with a rated impulse voltage of 4kV across these categories. The rated current is 16A according to IEC/EN standards, and under UL 1059, it has a rated voltage of 300V and rated currents of 15A for Use Group B and 10A for Use Group D. This connector accommodates 2 connection points and potentials, with a single connection type and level. The connection technology is Push-in CAGE CLAMP with push-button actuation, suitable for solid and fine-stranded conductors ranging from 0.2 to 2.5mm2 (24 to 12 AWG), and fine-stranded conductors with insulated or uninsulated ferrules from 0.25 to 2.5mm2. The strip length for connection is 9 to 10mm. It features a 2-pole configuration, 5mm pin spacing, and dimensions of 10mm in width, 35.4mm in height, and 13.4mm in depth. The design includes variable coding, gripping plate, and anti-rotation protection, with a female connector/socket type for conductor connection, without mismating protection and locking. The connector is made from light gray Polyphthalamide (PPA GF) with a flammability class of UL94 V0, Chrome-Nickel spring steel (CrNi) for the clamping spring, Electrolytic Copper (ECu) for contact material, and tin plating. It weighs 2g and can operate within a temperature range of -60 to +100°C. Packaged in boxes of 100 pieces, it is RoHS compliant without exemption, has a GTIN of 4050821163398, and is manufactured in Germany with a customs tariff number of 85366990990.
