714-134 WAGO Industrial Automation Components

714-134 on Powermatic Associates
WAGO

Part#:714-134

Manufacturer:WAGO

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

714-134 WAGO - THT male header; 0.8 x 0.8 mm solder pin; straight; Pin spacing 3.5 mm; 4-pole; black

Product Details

  • Weight
    0.900000237 g
  • Country Of Origin
    Germany
  • HTS Code
    85366990990
  • Width
    0.606 inches, 15.4 millimeters
  • Weight
    0.900 grams
  • Voltage
    150 volts, 160 volts
  • Package Type
    Box
  • Insulation Material
    Polyphthalamide
  • Height
    0.516 inches, 13.1 millimeters
  • Flammability Class
    V0
  • Depth
    0.272 inches, 6.9 millimeters
  • Current
    8 amperes, 8 amperes
  • Country of Origin
    Germany
  • Contact Type
    Tin
  • Connection Type
    For PCB
  • Color
    Black
  • Contact Material
    Copper

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 714-134 on Powermatic Associates is $1.65. Order now.


About the product

WAGO 714-134 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as specified in DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal and rated voltages of 160V and 320V under different conditions, and a rated impulse voltage of 2.5kV. The rated current is 8A. This part is UL 1059 approved, with a UL rated voltage of 150V and a rated current of 8A for Use Group B. It features four potentials, one connection type, and one level, with a pole number of four for the connection. The physical specifications include a pin spacing of 3.5mm, a width of 15.4mm, a height of 13.1mm, a depth of 6.9mm, and solder pin dimensions of 0.8 x 0.8mm. It offers variable coding, anti-rotation protection, and is designed for PCB with a 90-degree mating direction. The connector is made from black Polyphthalamide (PPA GF) with a flammability class of UL94 V0, and the contacts are made from Electrolytic Copper (ECu) with tin plating. It operates within a temperature range of -60 to +100°C and has a processing temperature range of -35 to +60°C. Packaged in boxes of 200 pieces, this product is RoHS compliant, with no exemptions, and originates from Germany (DE) with a GTIN of 4045454858841.


Manufacturer warranty

714-134 WAGO

$1.65

Your price can be lower.
Log in or Create account to check your discount

Select Qty:

$1.65

$1.65 each

Average response time: 11 minutes
