231-114/008-000 WAGO Industrial Automation Components
Part#:231-114/008-000
Manufacturer:WAGO
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
231-114/008-000 WAGO - Female plug; 14-pole; snap-in mounting feet; 12 AWG max; pin spacing 5 mm; 1 conductor per pole; gray
Product Details
- Weight 25.41000668 g
- Country Of Origin Germany
- HTS Code 85366990990
- Contact Material Copper Alloy
- Voltage 300 volts, 320 volts
- Depth 1.043 inches, 26.5 millimeters
- Flammability Class V0
- Connection Type For Conductor
- Package Type Box
- Actuator Operating Tool
- Height 0.74 inches, 18.8 millimeters
- Conductor Size 12 american wire gauge, 2.5 millimeters
- Mounting Type Panel Mounting, Snap-in Foot
- Country of Origin Germany
- Weight 25.410 grams
- Current 15 amperes, 16 amperes
- Width 2.815 inches, 71.5 millimeters
- Contact Type Tin
- Strip Length 0.35 inches, 9 millimeters
- Color Gray
- Insulation Material Polyamide
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 231-114/008-000 on Powermatic Associates is $13.62. Order now.
About the product
WAGO 231-114/008-000 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 320V (III/3), 320V (III/2), and 630V (II/2), rated impulse voltages of 4kV across these categories, and a rated current of 16A. UL and CSA approvals include ratings of 300V and 600V with currents ranging from 10A to 15A depending on the use group. The connector features 14 connection points, supports a single connection type with one level, and utilizes CAGE CLAMP technology for connection, compatible with solid and fine-stranded conductors of various sizes. It has a 14-pole number, 5mm pin spacing, and dimensions of 71.5mm in width, 18.8mm in height, and 26.5mm in depth. The housing allows for snap-in foot or panel mounting, includes anti-rotation protection, and is made from gray Polyamide (PA66) with a flammability class of UL94 V0. The connector's mechanical and material specifications ensure compatibility with a wide range of applications, operating within a temperature range of -60 to +85°C. It is RoHS compliant, with a packaging unit of 25 pieces per box, and is manufactured in Germany with a GTIN of 4044918341745.
