Name: FEN20-EN1
Brand: Turck

53113530

53113530 - LAPP SKINTOP® COLD Strain Relief Cable Gland - M25 x 1.5

Lapp

2

DK 26-631-3

Actuator and Sensor Cordset, Connection Cordset, , Straight Female M27 multifast Connector

Turck

2

QOB210

Square D by Schneider Electric QOB210 is a Miniature Circuit Breaker (MCB) designed for bolt-on mounting. It features a rated current of 10A and accommodates a bolt-on connection type. This MCB is compatible with a voltage rating of 48Vdc and 120V/240V AC, supporting a cross-section of 14-8AWG for 1 cable Al/Cu. It is a 2 Pole device with a short circuit breaking rating of 10kA at 240Vac and 5kA at 48Vdc. The terminals are of the press plate type.

Schneider Electric

5

RXM4AB2BD

Schneider Electric RXM4AB2BD is a miniature plug-in relay within the RXM sub-range, featuring contacts made from an Ag/Ni - Silver - Nickel alloy. This relay is designed with 4C/O - 4PDT (4 Pole Double Throw) contact type, and operates with a control voltage of 24 Vdc. It is rated for a current of 6 A at both 250Vac (AC-1) and 28Vac (DC-1). The RXM4AB2BD offers plug-in mounting mode and can operate within an ambient air temperature range of -40 to +55 °C. It has an IP40 degree of protection and a current consumption of 0.038 A. This model includes a visual position indicator through an LED, consumes 0.9 W of power, and boasts an electrical durability of 100,000 operations with a resistive load, alongside a mechanical durability of 10,000,000 operations at no load. Additionally, it features a Lockable Test Button (LTB) for latching.

Schneider Electric

53

PKGTAB

Schneider Electric PKGTAB, Load center accessory, QO/Homeline, insulator kit, for ground bars

Schneider Electric

3

MQDC1-506

Banner Engineering MQDC1-506 is a pre-assembled cable/cordset designed for various automation applications. It features a single-ended design with a 5.6mm diameter PVC cable and a length of 6.5ft (2m). The cable is equipped with a 5-pin Euro-style M12 female straight connector and bare end flying leads for connectivity. The connection nut is made from nickel-plated brass, ensuring durability. This model operates effectively within an ambient air temperature range of -40 to +105°C and offers a degree of protection rated at IP67, making it suitable for challenging environments. The cable's sheathing is black, and it is rated for a voltage of 250Vac.

Banner

184

EL1809

Beckhoff HD Ethercat Terminal, 16 Chnnl

Beckhoff

10

GV2P14

Schneider Electric GV2P14 is a Motor Protection Circuit Breaker (MPCB) within the GV2P sub-range, designed for thermal-magnetic motor protection and manual motor starting. It features 3 poles and provides protection functions against short-circuit and thermal overload. The rated current range is 6 - 10 A, with a rated insulation voltage (Ui) of 690 V. This MPCB is designed for DIN rail or mounting plate installation, has a net width of 45 mm, and is operated via a rotary knob. Protection settings for short-circuit pickup current are fixed at 138A. The rated impulse voltage (Uimp) is 6 kV, and it supports rated active powers of 3 kW at 400/415Vac, 5 kW at 500Vac, and 5.5 kW at 690Vac. The trip current rating is 10 AT, with a frame current rating of 32 AF. It boasts a mechanical durability of 100,000 operations at no load and an electrical durability of 100,000 operations at 415Vac in AC-3 condition. Connection is facilitated through screw-clamp terminals. The rated voltage for phase-to-phase is 690 V, with all three poles protected. The trip unit type is thermal-magnetic, supporting a minimum current of 6 A and a maximum current of 10 A, classified under utilisation category A AC-3.

Schneider Electric

10
