JGF36250 Schneider Electric Industrial Automation Components

JGF36250 on Powermatic Associates
Schneider Electric

Part#:JGF36250

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric JGF36250 is a Moulded Case Circuit Breaker (MCCB) from the PowerPacT JGF sub-range, designed with a PowerPact J-Frame 250 TMD 3P 250A 600Vac 18kA busbar at 80% rated. It features a Term. nut kit for fixed busbar connection on both line and load sides, with three poles (3P). The breaker offers thermal protection for overload and magnetic protection for short-circuit scenarios. It has a rated current of 250A, a rated insulation voltage (Ui) of 750 V, and operates at a rated voltage (AC) of 600Vac 600Y/347Vac. The unit is designed for individual mount on plate, with dimensions of 191 mm in height, 105 mm in width, and 127 mm in depth. It has a degree of protection of IP40 and operates manually via a toggle. Protection settings include over-current fixed at 250A and short-circuit pickup current adjustable between 1250A and 2500A. The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 250 AT, with a frame current rating of 250 AF. Its short circuit breaking rating varies with voltage, including 65kA at 240Vac, 35kA at 480Vac and 480Y/277Vac, 18kA at 600Vac and 600Y/347Vac, and 20kA at 250Vdc and 500Vdc, all under UL489. The trip unit type is thermal-magnetic (adjustable) without a display, and it falls under utilisation category A.

Product Details

  • Electrical Connection
    Busbar connection line Busbar connection load
  • Continuous Current Rating
    80 %
  • Depth
    5 in (127.00 mm)
  • Height
    7.52 in (191.01 mm)
  • Magnetic Hold Current
    1250 A
  • Tightening Torque
    230.12 lbf.in (26 N.m) 0.15…0.29 in² (95…185 mm²) (AWG 3/0...350 kcmil)
  • Magnetic Tripping Current
    2500 A
  • Width
    4.12 in (104.65 mm)
  • Product Or Component Type
    Circuit breaker
  • Breaking Capacity Code
    G
  • Number Of Poles
    3P

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of JGF36250 on Powermatic Associates is $5,001.00. Order now.
