Part#:JGF36225

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric JGF36225 is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT JGF sub-range, featuring a PowerPact J-Frame 250 TMD 3P 225A 600Vac 18kA busbar design rated at 80%. It includes a Term. nut kit for fixed busbar connection on both line and load sides, with three poles (3P). This MCCB offers thermal protection for overload and magnetic protection for short-circuit scenarios. It has a rated current of 225A, a rated insulation voltage (Ui) of 750 V, and operates at a rated voltage (AC) of 600Vac 600Y/347Vac. Designed for individual unit mount on plate, it measures 191 mm in height, 105 mm in width, and 127 mm in depth, with a degree of protection of IP40. The operating mode is manual toggle, with over-current protection fixed at 225A and short-circuit pickup current adjustable between 1125A and 2250A. It has a rated operating voltage (Ue) of 690 V, a rated impulse voltage (Uimp) of 8 kV, and a trip current rating of 225 AT. The frame current rating is 250 AF, with a short circuit breaking rating detailed across various voltages, including 65kA at 240Vac, 35kA at 480Vac, 18kA at 600Vac, and 20kA at 500Vdc, all under UL489. The trip unit type is thermal-magnetic (adjustable) without a display, and it falls under utilisation category A.

Product Details

  • Electrical Connection
    Busbar connection line Busbar connection load
  • Magnetic Tripping Current
    2250 A
  • Tightening Torque
    230.12 lbf.in (26 N.m) 0.15…0.29 in² (95…185 mm²) (AWG 3/0...350 kcmil)
  • Height
    7.52 in (191.01 mm)
  • Width
    4.12 in (104.65 mm)
  • Continuous Current Rating
    80 %
  • Depth
    5 in (127.00 mm)
  • Magnetic Hold Current
    1125 A
  • Breaking Capacity Code
    G
  • Number Of Poles
    3P
  • Product Or Component Type
    Circuit breaker

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of JGF36225 on Powermatic Associates is $5,668.50. Order now.
