HDL36030T Schneider Electric Electronic Components

HDL36030T on Powermatic Associates
Schneider Electric

Part#:HDL36030T

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric HDL36030T is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HDL sub-range. It features a removable/interchangeable trip unit PowerPact H-Frame 150 TMD with 3 poles (3P) and a rated current of 30A. This MCCB is designed for 600Vac/250Vdc with a 14kA breaking capacity and includes lugs on both load and line sides for connection. It offers thermal protection for overload and magnetic protection for short-circuit situations. The rated insulation voltage (Ui) is 750 V, with a rated voltage (AC) of 600Vac 600Y/347Vac and a rated voltage (DC) of 250Vdc. The unit is designed for individual mount on plate, with a net height of 163 mm, width of 104 mm, and depth of 86 mm. It has an IP40 degree of protection and operates with a toggle (manual) mechanism. Protection settings are fixed, with over-current at 30A, short-circuit hold current at 350A, and short-circuit trip current at 750A. The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 30 AT, and the frame current rating is 150 AF. The short circuit breaking rating varies with voltage, up to 25kA at 240Vac and 20kA at 250Vdc, according to UL489 standards. The trip unit type is thermal-magnetic (fixed) without a display, and it falls under utilisation category A.

Product Details

  • Width
    4.12 in (104.65 mm)
  • Line Rated Current
    30 A
  • Breaking Capacity Code
    D
  • Height
    6.4 in (162.56 mm)
  • Magnetic Tripping Current
    750 A
  • Depth
    4.36 in (110.74 mm)
  • Product Or Component Type
    Circuit breaker
  • Magnetic Hold Current
    350 A
  • Range Of Product
    PowerPact H
  • Mounting Mode
    Unit mount
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Number Of Poles
    3P
  • Continuous Current Rating
    80 %
  • Electrical Connection
    Lugs load Lugs line

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
