LC1F225L7 Schneider Electric Electronic Components

LC1F225L7 on Powermatic Associates
Schneider Electric

Part#:LC1F225L7

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Only 1 left in stock. Order Now!

Mar 30, 2025

Product description

Schneider Electric LC1F225L7 is a high-power magnetic contactor within the F sub-range, designed for surface mounting. It features a 3-pole (3P; 3NO) configuration with ring-lugs/bar connections. The contactor is rated for currents of 315A under AC-1 conditions and 225A at 440Vac under AC-3 conditions. It operates with a control voltage range of 177-228Vac (208Vac nominal; 40-400Hz; 0.85...1.1 x Uc) and has a rated operating voltage (Ue) of 1000 V. This model comes without normally open (NO) or normally closed (NC) auxiliary contacts. It is capable of handling rated impulse voltages (Uimp) up to 8 kV and supports rated active power (kW) of 63kW at 220-230Vac, 110kW at 380-400Vac, 415Vac, and 440Vac, 129kW at 500Vac and 660-690Vac, and 100kW at 1000Vac, all under AC-3 conditions. The LC1F225L7 boasts a mechanical durability of 10 million operations at no load and is designed for phase-to-phase rated voltages (AC) up to 1000 V.

Product Details

  • Product Certifications
    CCC CB ABS BV RINA UL RMRoS DNV LROS (Lloyds register of shipping) UKCA
  • Motor Power Kw
    110 kW 380...400 V AC 50/60 Hz AC-3) 110 kW 415 V AC 50/60 Hz AC-3) 110 kW 440 V AC 50/60 Hz AC-3) 129 kW 500 V AC 50/60 Hz AC-3) 129 kW 660...690 V AC 50/60 Hz AC-3) 63 kW 220...230 V AC 50/60 Hz AC-3) 40 kW 400 V AC 50/60 H
  • [Icw] Rated Short-Time Withstand Current
    1800 A 104 °F (40 °C) - 10 s 1000 A 104 °F (40 °C) - 30 s 850 A 104 °F (40 °C) - 1 min 560 A 104 °F (40 °C) - 3 min 440 A 104 °F (40 °C) - 10 min
  • Standards
    EN 60947-1 IEC 60947-1 EN 60947-4-1 IEC 60947-4-1 JIS C8201-4-1
  • Connections - Terminals
    Control circuit screw clamp terminals 1 0.00…0.01 in² (1…4 mm²)flexible without cable end Control circuit screw clamp terminals 2 0.00…0.01 in² (1…4 mm²)flexible without cable end Control circuit screw clamp terminals 1 0.00…0.01 in² (1…4 mm²)fl
  • Utilisation Category
    AC-3 AC-4 AC-1
  • Control Circuit Voltage Limits
    Operational 0.85...1.1 Uc 40...400 Hz 131 °F (55 °C)) Drop-out 0.35...0.55 Uc 40...400 Hz 131 °F (55 °C))
  • [Ui] Rated Insulation Voltage
    1000 V IEC 60947-4-1 1500 V VDE 0110 group C
  • [Ie] Rated Operational Current
    315 A 104 °F (40 °C)) <= 440 V AC-1 225 A 131 °F (55 °C)) <= 440 V AC-3
  • Power Dissipation Per Pole
    32 W AC-1 16 W AC-3
  • Contactor Application
    Resistive load Motor control
  • [Ue] Rated Operational Voltage
    <= 460 V DC <= 690 V AC 50/60 Hz
  • Tightening Torque
    Control circuit 10.62 lbf.in (1.2 N.m) Power circuit 309.78 lbf.in (35 N.m)
  • Operating Time
    35 ms closing at Uc) 130 ms opening at Uc)
  • Associated Fuse Rating
    315 A gG <= 440 V 250 A aM <= 440 V
  • Maximum Operating Rate
    2400 cyc/h 131 °F (55 °C)
  • Compatibility Code
    LC1F
  • Mechanical Durability
    10 Mcycles
  • Inrush Power In VA
    1070 VA 40...400 Hz 0.9 68 °F (20 °C))
  • Hold-In Power Consumption In VA
    9.9 VA 40...400 Hz 0.9 68 °F (20 °C))
  • Heat Dissipation
    8…9.8 W
  • Average Impedance
    0.32 mOhm - Ith 315 A 50 Hz
  • Mounting Support
    Plate
  • Rated Breaking Capacity
    1800 A IEC 60947-4-1
  • [Ith] Conventional Free Air Thermal Current
    315 A 104 °F (40 °C)
  • Overvoltage Category
    III
  • [Uimp] Rated Impulse Withstand Voltage
    8 kV
  • [Uc] Control Circuit Voltage
    208 V AC 40...400 Hz
  • Poles Description
    3P
  • Range
    TeSys
  • Device Short Name
    LC1F
  • Power Pole Contact Composition
    3 NO
  • Product Or Component Type
    Contactor
  • Product Name
    TeSys F

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

LC1F225L7 Related Documents

Instruction Sheet-1631038440069.pdfCatalog-1631038440089.pdfProduct Datasheet-1631038440074.pdf
