Part#:EJB16035

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Mini circuit breaker, E-Frame, 35A, 1 pole, 600Y/347 VAC, 100 kA max, bolt on

Product Details

  • AWG Gauge
    AWG 12...AWG 2/0 aluminium AWG 14...AWG 2/0 copper
  • Tightening Torque
    34.52 lbf.in (3.9 N.m) 0.00…0.01 in² (2.5…6 mm²) (AWG 14...AWG 10) 49.56 lbf.in (5.6 N.m) 0.02…0.11 in² (10…70 mm²) (AWG 8...AWG 2/0)
  • Protection Type
    Short-circuit Overload
  • Net Weight
    2 lb(US) (0.91 kg)
  • Breaking Capacity Code
    J
  • Depth
    4.05 in (102.87 mm)
  • Width
    0.98 in (24.89 mm)
  • Height
    5.66 in (143.76 mm)
  • Number Of Spaces Required
    1
  • Product Destination
    NF panelboard
  • Trip Unit Technology
    Thermal-magnetic
  • Mounting Mode
    Bolt-on
  • Number Of Spaces
    1
  • Number Of Poles
    1
  • Circuit Breaker Application
    HACR rated
  • Local Signalling
    Trip indicator
  • Holding Current
    630 A
  • Electrical Connection
    Lugs aluminium
  • Breaking Capacity
    25 kA 600Y/347 V AC
  • Maximum Operating Voltage
    600Y/347 V AC
  • Line Rated Current
    35 A
  • Trip Unit Rating
    1800 A
  • Module Type
    E-Frame
  • Device Short Name
    EJB
  • Product Or Component Type
    Circuit-breaker
  • Range Of Product
    125 A Frame EDB-EGB-EJB

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
