EGB14045 Schneider Electric Industrial Automation Components
Part#:EGB14045
Manufacturer:Schneider Electric
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
Square D by Schneider Electric EGB14045 is a Miniature Circuit Breaker (MCB) designed for bolt-on mounting with a visual trip indicator. It features lugs type terminals and is rated for 277V AC. This MCB offers protection functions against short-circuit and overload conditions and serves as both an Equipment Protection Device (EPD) and a Circuit Breaker (CB) with a breaking capacity code G. It utilizes an aluminium lugs connection and supports a rated current of 45A across 1 Pole(s). The cross-section compatibility ranges from 12-2/0AWG. It has a short circuit breaking rating of 65kA at 120Vac, 35kA at 240Vac, and 35kA at 277Vac. The trip unit is of the thermal-magnetic type with protection settings featuring a trip unit rating of 1800A.
Product Details
- Breaking Capacity 35 kA 277 V AC 35 kA 240 V AC 65 kA 120 V AC 35 kA 120/240 V AC
- AWG Gauge AWG 12...AWG 2/0 aluminium AWG 14...AWG 2/0 copper
- Tightening Torque 34.52 lbf.in (3.9 N.m) 0.00…0.01 in² (2.5…6 mm²) (AWG 14...AWG 10) 49.56 lbf.in (5.6 N.m) 0.02…0.11 in² (10…70 mm²) (AWG 8...AWG 2/0)
- Protection Type Short-circuit Overload
- Circuit Breaker Application HACR rated HID rated
- Breaking Capacity Code G
- Trip Unit Technology Thermal-magnetic
- Height 5.66 in (143.76 mm)
- Net Weight 2 lb(US) (0.91 kg)
- Width 0.98 in (24.89 mm)
- Depth 4.05 in (102.87 mm)
- Product Destination NF panelboard
- Number Of Poles 1
- Number Of Spaces 1
- Local Signalling Trip indicator
- Electrical Connection Lugs aluminium
- Mounting Mode Bolt-on
- Number Of Spaces Required 1
- Holding Current 630 A
- Device Short Name EGB
- Trip Unit Rating 1800 A
- Line Rated Current 45 A
- Range Of Product 125 A Frame EDB-EGB-EJB
- Product Or Component Type Miniature circuit-breaker
- Maximum Operating Voltage 277 V AC
- Module Type E-Frame
