PAXLA0U0 Red Lion Industrial Automation Components

PAXLA0U0 on Powermatic Associates
Red Lion

Part#:PAXLA0U0

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion PAXLA0U0 is a label kit accessory designed for marking purposes. It is compatible with specific models but is not required for DP5T or PAXT units.

Product Details

  • Main function
    Meter (Digital)
  • Supply voltage (DC)
    21.6-250Vdc (24Vdc / 48Vdc / 60Vdc / 72Vdc / 100Vdc / 110Vdc / 120Vdc / 127Vdc / 200Vdc / 220Vdc / 250Vdc)
  • Primary brand
    Red Lion
  • Product series / family name
    Process indicators
  • Functions
    DC universal digital meter
  • Sub-range name
    PAX Lite series
  • Supply voltage (AC)
    50-250Vac (48Vac / 100Vac / 110Vac / 120Vac / 200Vac / 208Vac / 220Vac / 230Vac / 240Vac)
  • Design
    1 user input 1/8 DIN (96x48mm)
  • Compliant with standard(s)
    CE IEC 60068-2-6 (vibration) EN 61326-1 immunity to industrial locations EN 61010-1 EN 61010-2-030 UL Listed RoHS compliant
  • Display
    1 row x 5-digits red characters (14.2mm / 0.56" high) LED display
  • Dimensions
    1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95")
  • Digital inputs
    1 x digital inputs (Sink/Source) (USER INPUT)
  • Order code / Manufacturer SKU
    PAXLA0U0
  • Digital outputs
    2 x digital outputs (contact type SPDT) (reached setpoints 1 & 2)
  • Degree of protection
    IP65 NEMA 4X
  • Analog inputs
    1 x analog input (0-200mV / 0-0.01mV / 0-0.1mV / 0-200V / 0-200μA / 0-2mA / 0-20mA / 0-200mA / 4-20mA / 1-5V / 1-10Vdc; 16-bits conversion)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

PAXLA0U0 Related Documents

Red Lion - PAXLA - Product Manual.pdf
