G10S0000 Red Lion Industrial Automation Components

G10S0000 on Powermatic Associates
Red Lion

Part#:G10S0000

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Only 1 left in stock. Order Now!

Apr 24, 2025

Product description

Red Lion G10S0000 is an HMI / Display unit from the HMI Rugged Graphite series designed for both indoor and outdoor use. It features an HMI operator touchscreen panel with a connection interface that includes 1 x RJ45 port for Ethernet, 2 x RJ11 ports for RS-232, and 1 x RJ45 port supporting both RS-422 and RS-485 communication protocols. The unit operates on a supply voltage range of 10-30Vdc, accommodating both 12Vdc and 24Vdc systems. It is engineered to function within an ambient air temperature range of -20 to +60 °C and offers a degree of protection rated at IP66 and NEMA 4X. The G10S0000 is equipped with 7 module slots for connection capacity, and its power consumption is typically 18 W, with a maximum of 53 W. The electrical durability of the backlight is rated at 35,000 hours. For storage, it includes an SD card slot, and it boasts a brightness level of 2500cd/m2.

Product Details

  • Sub-range name
    HMI Rugged Graphite series
  • Connection type
    1 x RJ45 port (Ethernet) 2 x RJ11 ports (RS-232) 1 x RJ45 port (RS-422 / RS-485)
  • Compliant with standard(s)
    CE ANSI/ISA 12.12.01 IEC/EN 61010-1 IEC 60068-2-6 (vibration) EN 61326-1 immunity to industrial locations UL 61010-1 /-2-201 C22.2 No. 213-M1987; 157-92 RoHS compliant ABS UL Listed (Class I Division 2 Groups A/B/C/D) UL Listed (Class II Division 2 Groups
  • Mounting location
    Outdoor Indoor
  • Supply voltage (DC)
    10-30Vdc (12Vdc / 24Vdc)
  • Degree of protection
    IP66 NEMA 4X
  • Communication protocol
    RS-232 RS-422 RS-485 Ethernet
  • Order code / Manufacturer SKU
    G10S0000
  • Brightness
    2500cd/m2
  • Main function
    HMI / Display unit
  • Design
    for indoor / outdoor use
  • Replaces
    G310S210
  • Product series / family name
    HMIs (Human-Machine Interfaces)
  • Connection capacity
    7 x module slots
  • Ambient air temperature for operation
    -20...+60 °C
  • Benefits
    Sleek full-color HMI touchscreens Versatile module and expansion options Rugged environmental specifications Industry-Leading protocol conversion Powerful integration functionality
  • Storage type
    SD card slot
  • Primary brand
    Red Lion
  • Display
    10" / 640x480pixels (VGA) touchscreen LCD 16.7M colors display with backlight
  • Functions
    HMI operator touchscreen panel
  • Power consumption
    (Typical) 18 W(Maximum) 53 W
  • Electrical durability
    (Backlight) 35 000 hours

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

G10S0000 Related Documents

Red Lion - Industrial Automation Product Guide.pdfRed Lion - Graphite HMIs - Data Sheet.pdf
