3049013 Phoenix Contact Terminal Blocks
Part#:3049013
Manufacturer:Phoenix Contact
Category:Terminal Blocks
Product Lifecycle:Active
Mar 14, 2025
Product description
Bolt connection terminal block, Note: the BE-RT... path extension is to be used for non-insulated cable lugs (see accessories)., nom. voltage: 1000 V, nominal current: 24 A, connection method: Bolt connection, number of connections: 2, width: 12.3 mm, col
Product Details
- Tightening torque max 0.8 Nm
- ECLASS 4.1 27141100
- ETIM 3.0 EC000897
- ETIM 7.0 EC000897
- ECLASS 6.0 27141100
- UNSPSC 19.0 39121410
- UNSPSC 18.0 39121410
- UNSPSC 11 39121410
- UNSPSC 21.0 39121410
- ECLASS 4.0 27141100
- China RoHS Environmentally friendly use period: unlimited = EFUP-e
- Bolt diameter 3 mm
- ECLASS 5.1 27141100
- Nominal voltage UN 1000 V (Rated voltage for open disconnect point 500 V)
- Back of the hand protection guaranteed
- Result of the test for mechanical stability of terminal points (5 x conductor connection) Test passed
- Setpoint 1 N
- Potentials 1
- Flammability rating according to UL 94 V0
- Maximum power dissipation for nominal condition 0.77 W
- Smoke gas toxicity NFPA 130 (SMP 800C) passed
- Fire protection for rail vehicles (DIN EN 45545-2) R26 HL 1 - HL 3
- Length 66 mm
- Note Note: the BE-RT... path extension is to be used for non-insulated cable lugs (see accessories).
- Insulating material PA
- Insulating material group I
- Shock protection test specification DIN EN 50274 (VDE 0660-514):2002-11
- Note regarding shock protection Electric shock protection only with insulated cable lug and closed wing flap guaranteed.
- Result of voltage-drop test Test passed
- Tight fit on carrier NS 35
- Short-time current 0.3 kA
- Test frequency f1 = 5 Hz to f2 = 150 Hz
- Test directions X-, Y- and Z-axis (pos. and neg.)
- Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)) 130 °C
- End cover width 2.2 mm
- Number of connections 2
- Color gray
- Rated surge voltage 8 kV
- Maximum load current 24 A (with a 2.5 mm² conductor cross section)
- Finger protection guaranteed
- Power frequency withstand voltage setpoint 2.2 kV
- Short circuit stability result Test passed
- Test specification, oscillation, broadband noise DIN EN 50155 (VDE 0115-200):2008-03
- Result of thermal test Test passed
- Shock test result Test passed
- Test duration per axis 5 h
- Number of levels 1
- Area of application Railway industry
- Overvoltage category III
- Nominal current IN 24 A
- Result of surge voltage test Test passed
- Result of tight fit on support Test passed
- Conductor cross section short circuit testing 2.5 mm²
- Test spectrum Service life test category 1, class B, body mounted
- Proof of thermal characteristics (needle flame) effective duration 30 s
- Acceleration 5g
- Shock duration 30 ms
- Surface flammability NFPA 130 (ASTM E 162) passed
- Nominal cross section 2.5 mm²
- Degree of pollution 3
- Open side panel Yes
- Result of power-frequency withstand voltage test Test passed
- Result of temperature-rise test Test passed
- Shock form Half-sine
- UNSPSC 13.2 39121410
- Number of shocks per direction 3
- Test specification, shock test DIN EN 50155 (VDE 0115-200):2008-03
- Calorimetric heat release NFPA 130 (ASTM E 1354) 28 MJ/kg
- Fire protection for rail vehicles (DIN EN 45545-2) R23 HL 1 - HL 3
- Stripping length The stripping length depends on the specification provided by the cable lug manufacturer.
- Height NS 35/15 58.5 mm
- AWG min 18
- Oscillation, broadband noise test result Test passed
- Height NS 35/7,5 51 mm
- Connection method Bolt connection
- Max. cross section for cable lug connection 2.5 mm²
- Hole diameter, min. 3.2 mm
- ECLASS 7.0 27141120
- ASD level 1.857 (m/s2)2/Hz
- Relative insulation material temperature index (Elec., UL 746 B) 130 °C
- Specific optical density of smoke NFPA 130 (ASTM E 662) passed
- Screw thread M3
- Ambient temperature (actuation) -5 °C ... 70 °C
- Ambient temperature (storage/transport) -25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
- ECLASS 10.0.1 27141120
- ETIM 2.0 EC000897
- REACh SVHC Lead 7439-92-1
- ECLASS 11.0 27141120
- ECLASS 9.0 27141120
- ETIM 6.0 EC000897
- UNSPSC 7.0901 39121410
- UNSPSC 20.0 39121410
- Requirement temperature-rise test Increase in temperature ≤ 45 K
- Static insulating material application in cold -60 °C
- Width 12.3 mm
- Min. cross section for cable lug connection 1 mm²
- Connection in acc. with standard CUL
- AWG max 14
- Tightening torque, min 0.6 Nm
- Ambient temperature (assembly) -5 °C ... 70 °C
- Cable lug width, max. 6 mm
- Operating temperature -60 °C ... 105 °C (max. short-term operating temperature 130°C)
- Permissible humidity (storage/transport) 30 % ... 70 %
- ECLASS 5.0 27141100
- Fire protection for rail vehicles (DIN EN 45545-2) R22 HL 1 - HL 3
- Fire protection for rail vehicles (DIN EN 45545-2) R24 HL 1 - HL 3
- Connection 1 level
- Cable lug connection according to standard DIN 46237:1970-07
- ETIM 4.0 EC000897
- UNSPSC 6.01 30211811
- UNSPSC 12.01 39121410
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
