FSD87-25-Q Panduit Electronic Components

Product Details

• Part Features
  Polypropylene insulation housing conforms to DIN color requirements Meets DIN, UL and CSA standards for single wire containment Funnel entry for faster insertion and lower installed cost Designed with a seamless barrel to contain loose wire strands for
• Minimum Copper Conductor Size (AWG SOL)
  NA
• Base Material
  Copper
• Packaging Type
  Loose Piece Ferrules
• Maximum Operating Temperature (°F)
  221
• Overall Length (In.)
  1.61
• Maximum Wire Insulation Diameter (mm)
  15
• Insulation Diameter (In.)
  0.59
• Wire Strip Length (mm)
  28.6
• Sub Brand
  DIN 46228 Part 4, UL 486F Listed, CSA
• Minimum Copper Conductor Size (AWG STR)
  NA
• Maximum Copper Conductor Size (AWG STR)
  NA
• Maximum Copper Conductor Size (AWG SOL)
  NA
• For Use With
  NA
• Product Type
  Insulated single wire ferrules (DIN or French color code)
• Finish/Coating
  Tin-Plated
• Standards Met
  DIN 46228 Part 4, CSA C22.2 No. 291-14
• Overall Length (mm)
  41
• Maximum Operating Temperature (°C)
  105
• Maximum Wire Insulation Diameter (In.)
  0.59
Inside Diameter (mm)
10.5
Inside Diameter (In.)
0.41
Insulation Diameter (mm)
15
Minimum Copper Conductor Size (AWG)
NA
Insulation Type
Polypropylene
Pin Length (In.)
0.98
Pin Length (mm)
25
Wire Strip Length (In.)
1.13
Flammability Rating
UL 94 HB
Insulation Material
Polypropylene
