FSD86-16-L Panduit Industrial Automation Components

Product Details

• Shipping Height:
  1.00 In.
• Shipping Width:
  8.00 In.
• UPC:
  074983762743
• Shipping Length:
  5.00 In.
• Shipping Weight:
  0.15 lbs.
• Part Features
  Polypropylene insulation housing conforms to DIN color requirements Meets DIN, UL and CSA standards for single wire containment Funnel entry for faster insertion and lower installed cost Designed with a seamless barrel to contain loose wire strands for
• Sub Brand
  DIN 46228 Part 4, UL 486F Listed, CSA
• Minimum Copper Conductor Size (AWG STR)
  NA
• Maximum Copper Conductor Size (AWG STR)
  NA
• Minimum Copper Conductor Size (AWG SOL)
  NA
• Maximum Copper Conductor Size (AWG SOL)
  NA
• Base Material
  Copper
• Packaging Type
  Loose Piece Ferrules
• Standards Met
  DIN 46228 Part 4, CSA C22.2 No. 291-14
• For Use With
  NA
• Finish/Coating
  Tin-Plated
• Product Type
  Insulated single wire ferrules (DIN or French color code)
• Overall Length (In.)
  1.18
• Overall Length (mm)
  30
• Maximum Wire Insulation Diameter (mm)
  12.5
Maximum Wire Insulation Diameter (In.)
0.49
Maximum Operating Temperature (°F)
221
Maximum Operating Temperature (°C)
105
Inside Diameter (mm)
8.5
Insulation Diameter (mm)
12.5
Inside Diameter (In.)
0.33
Insulation Type
Polypropylene
Pin Length (mm)
16
Insulation Diameter (In.)
0.49
Pin Length (In.)
0.63
Wire Strip Length (mm)
19.1
Wire Strip Length (In.)
0.75
Flammability Rating
UL 94 HB
Minimum Copper Conductor Size (AWG)
NA
Insulation Material
Polypropylene
